Taylor C712 Operating Instructions

45
Model C712
Parts List
DESCRIPTION COMMENTSWARR.
CLASS
QTY.PART
NUMBER
CAP-DESIGN 1.010"ID-6 POINT 014218 3 NNN O-RING-7/8 OD X .103W 014402 5 NNN O-RING-1/2OD X .070W 024278 4 NNN SEAL-DRAW VALVE 034698 1 NNN
KIT A.-BARREL *TWIN SS*8784* 1 X56200-6 1 103
SEAL-DRIVE SHAFT 032560 2 NNN GASKET-DOOR-4"-DART 048926-1 2 000 SHOE-FRONT HELIX *REAR* 050346 2 000 SHOE-FRONT HELIX *FRONT* 050347 2 000 BEARING-FRONT-SHOE 050348 2 000
TOOL-O-RING REMOVAL-FREEZER 048260-WHT 1 000
KIT-MOUNTING-COMPRESSOR CS 052197 2 000 LABEL-SW-POWER-OFF/ON-SYMBOLS 052632 1 000 LUBRICANT-TAYLOR 4 OZ. 047518 1 000 MANIFOLD-1/2S THRU-1/4S OUT-2 046687 2 NNN LINE DISCHARGE MAN-OPER C712 062179-M 1 000 MOTOR-1.5 HP CAPS@10&2 O'CLOCK 021522-27 2 212 208-230V 60HZ 1PH MOTOR-1.5 HP 021522-33 2 212 208-230V 60HZ 3PH MOTOR-1.5 HP CAPS@10&2 O'CLOCK 021522-34 2 212 220-240V 50HZ 1PH MOTOR-1.5 HP 021522-35 2 212 380-415V 50HZ 3N MOTOR-FAN 062253-27 1 103 AUX MOTOR-REDUCER 32 RPM-HPR PUMPM 036955-34 2 212 MIX PUMP NUT-STUD-BLACK 2.563 LONG 058764 2 103 NUT-STUD-BLACK 3.250 LONG 058765 2 103 ORIFICE 022465-100 2 103
+O-RING-3/8 OD X .070W 016137 2 000
PAIL-MIX 10 QT. 013163 1 000 PAN-DRIP 7.875 059737 2 NNN PAN-DRIP 12.5 059736 2 NNN PAN-DRIP 19-1/2 LONG 035034 1 103 PANEL A.-FILTER-LOUVERED X59928 2 103 PANEL A.-FRONT *C712/C716* X63879 1 103 MIDDLE FRONT UNDER NOSE CONE
