Taylor C722 Operating Instructions

9
Model C722 Operator Parts Identification
Model C722 Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1 COVER-HOPPER-14 QT BLACK 041682-BLA
2 ORIFICE 022465-100
3 O-RING-3/8 OD X .070W 016137
4 TUBE A.-FEED-SS-5/32 HOLE X29429-2
5 O-RING-.643 OD X .077W 018572
6 PANEL-REAR 080162
7 PANEL A.-SIDE RIGHT X68854
8 PANEL A.-FRONT X68777
9 SCREW-1/4-20X3/8 SLOTTED 011694
10 PANEL A.-FRONT-LOWER X68858
11 SHELF-DRIP TRAY 068863
ITEM DESCRIPTION PART NO.
12 TRAY-DRIP 068864
13 SHIELD-SPLASH 049203
14 PAN A.-DRIP 15 1/8 LONG X51601
15 STUD-NOSE CONE 055987
16 PANEL-SIDE LEFT 068851
17 FILTER-AIR-21.688X15.813H 052779-9
18 COVER-ACCESS-FRONT-R. 068844
19 SCREW-10X3/8 SLOTTED HEX 015582
20 COVER-ACCESS-LEFT 068869
21 BLADE A.-AGITATOR X56591-SP
22 PAN-DRIP-REAR 080226
