Taylor C850 Series - C850;C852 left Side View

9
C850/C852 left Side View (See Figure 4.)
Figure 4
ITEM PART NO. DESCRIPTION QTY. FUNCTION WARR.
CLASS
1 084170 Handle-Grill 1
(C850)
2
(C852)
The handle clicks in to the platen latch
when in the down position.
