18
Important to the Operator
Important to the Operator Exploded View (See Figure 10.)
ITEM DESCRIPTION FUNCTION
1 Fan Interlock Switch Activates power to the grill and the exhaust fans.
2 Clean Key Takes the grill into the ready mode for cleaning.
3 Settings Key Displays a pass code screen to allow the manager to enter the pass code
and enter the Manager menu. From the Manager menu, the manager
can make adjustments to the Date/Time, Temperature Scale, Volume,
Brightness, Language, and Firmware Manager functions.
4 Cook Time Key Allows the user to set the Cook Time.
5 Recipe Filter Key Allows the user to choose the grill mode (auto or manual) and toggle
between AM, PM and ALLDAY modes.
6 Date/Time Key Allows the user to enter the date and time of day.
7 General Key Displays the Temperature Scale, Firmware and About screens.
8 Display Key Displays the Brightness and Font Limit screens.
9 Auto Level Key Allows the user to Auto Calibrate and Gap Check.
10 Help Key Future development
11 Menu Key Displays the main screen.
12 Recipe Key Allows the user to choose a product.
13 Back Arrow Key Returns the user to the previous screen.
14 Off Key Turns the grill controller off.
15 Language Key Sets the desired language.
16 Volume Key Sets the desired volume.
17 Notification/Warning Key Displays the recent faults and events.
18 Information Key Displays current status of machine (examples: temperatures of upper
platens and lower cook surfaces, date when last cleaning was performed,
date when last product integrity was performed.)
19 Home Key Enters the main menu.
