Taylor C850 Series User Manual

5
Parts Identification/Function and Exploded View
C850 Exploded View (See Figure 1.)
ITEM PART NO. DESCRIPTION QTY. FUNCTION WARR.
CLASS
1 X84969 CAN A.-GREASE-L 1 Container for grease. 103
2 X84224 SHROUD-UPPER SIDE 1 Metal bracket that the grease can
slides into, securing it next to the
lower grill plate.
103
3 070695 SCREW-10-32X1/2 PHIL 4 Fastens bumpers to panels. 000
4 084549 BUMPER 1 Protects grill from damage. 000
5 X73600-SER KIT A.-GREASE SHIELD 2 Fastens grease shields to rear shroud. 000
6 082959 PANEL-REAR 1 Provides access to internal
components for service and cleaning.
103
7 024298 SCREW-10-32X3/8 PHIL 34 Secures the panel to the frame. 000
8 082958 PANEL-SIDE-RIGHT 1 Provides access to internal
components for service and cleaning.
103
9 078377 CASTER-5” 7-5/8 STEM 2 Allows grill mobility. 103
10 X84608 CAN A.-GREASE-R 1 Container for grease. 103
11 X84225 SHROUD-UPPER SIDE 1 Metal bracket that the grease can
slides into, securing it next to the
lower grill plate.
103
12 081974 CASTER-5” 7-5/8
STEM-BRAKE
2 Prevents grill movement when the
brake is used.
103
13 076989-WP SWITCH-ROCKER-
DPST 10A
1 Activates power to the grill and the
exhaust fans.
103
14 X84230 DOOR A.-CONTROL 1 Houses the controls. 103
15 083786 TOUCHSCREEN-UI 1 Controls all functions of the grill. - - -
16 068583 COVER A.-USB
WATERPROOF
1 Protects USB port from water
damage.
103
17 075288 GUARD-LENSE
(INTERNATION USE
ONLY)
1 Protects the STANDBY button and
accidentally starting a cook cycle. For
international use only.
103
18 076012 BUTTON-OPERATOR-
BLACK
1 Activates the cook cycle, keeps the
upper platen in the closed position,
and displays “STANDBY” on the
control. When pressed twice with one
second intervals between presses, the
upper platen will automatically lower
into the Standby position.
000
19 076011 BUTTON-OPERATOR-
RED
1 Cancels Standby mode, raises the
upper platen and deactivates the
Cook cycle.
000
20 X85465 SHIELD A.-REAR GRS 1 Prevents grease migration. 000
21 082957 PANEL-SIDE-LEFT 1 Provides access to internal
components for service and cleaning.
103
22 084613 BUMPER 1 Protects the grill from damage. 000
