Taylor C850 Series User Manual

7
C852 Exploded View (See Figure 2.)
ITEM PART NO. DESCRIPTION QTY. FUNCTION WARR.
CLASS
1 X84969 CAN A.-GREASE-L 2 Container for grease. 103
2 X84224 SHROUD A.-UPPER*LFT 1 Metal bracket that the grease can
slides into, securing it next to the
lower grill plate.
103
3 070695 SCREW-10-32X1/2 PHIL 4 Fastens bumper onto panel. 000
4 084549 BUMPER 1 Protects grill from damage. 000
5 X73600-SER KIT A.-GREASE SHIELD 4 Fastens grease shields to rear shroud. 000
6 084215 PANEL-REAR 1 Provides access to internal
components for service and cleaning.
103
7 024298 SCREW-10-32X3/8 SLTD
TRUSS
54 Secures the panel to the frame. 000
8 082958 PANEL-SIDE-RIGHT 1 Provides access to internal
components for service and cleaning.
103
9 078377 CASTER-5” 7-5/8 STEM 2 Allows grill mobility. 103
10 X84608 CAN A.-GREASE-R 2 Container for grease 103
11 X84225 SHROUD A.-UPPER*RT
1
Metal bracket that the grease can
slides into, securing it next to the
lower grill plate.
103
12 073240 CASTER-5” 7-5/8
SWIVEL W/LOCK
2 Prevents grill movement when the
lock is used.
103
13 076989-WP SWITCH-ROCKER-
DPST 10A
1 Activates power to the grill and the
exhaust fans.
103
14 X84265-23 CONTROL A.-RIGHT 1 Controls all functions of the grill. - - -
15 083786 TOUCHSCREEN-UI 1 Controls all functions of the grill. - - -
16 X84255 DOOR A.-WELDED 2 Houses the controls and the fan
interlock switch.
103
17 068583 COVER A.-USB
WATERPROOF
2 Protects USB port from water
damage.
103
18 075288 GUARD-LENSE
(INTERNATIONAL USE
ONLY)
2 Protects the Standby button and and
accidentally starting a cook cycle For
international use only.
000
19 076012 BUTTON-OPERATOR-
BLACK
2 Activates the cook cycle, keeps the
upper platen in the closed position,
and displays the message
“STANDBY” on the control. When
pressed twice with one second
intervals between presses, the upper
platen will automatically lower into the
Standby position.
000
20 076011 BUTTON-OPERATOR-
RED
2 Cancels the Standby mode, raises the
upper platen, and deactivates the
Cook cycle.
000
21 X85465 SHIELD A.-REAR-GRS 2 Prevents grease migration. 000
22 082957 PANEL-SIDE-LEFT 1 Provides access to internal
components for service and cleaning.
103
23 084613 BUMPER 1 Protects grill from damage. 000
