OPERATING PROCEDURES
6-5
Model SB25
Operating Procedures
6
10. Remove the ice hopper and cover. Take them to the
three compartment sink for cleaning and sanitizing.
(See Figure 6-12.)
Figure 6-12
11. Remove the blender pitchers, splash guard, and ice
chute. Take them to the three compartment sink for
cleaning and sanitizing.
12. For machines equipped with Rinse Station:
Remove the Rinse Station assembly (grates,
actuator, pivot rod and rinse pan). Take them to the
three compartment sink for cleaning and sanitizing.
13. Brush-clean the parts in the three compartment sink.
Note: Do not place the parts in the power soaker sink or
dishwasher.
CAUTION! Use care when washing the
blender pitcher. DO NOT touch the pitcher blades with
your hands. Failure to follow this instruction may result in
personal injury from blade contact.
14. Rinse the parts in cool, clean water.
15. Sanitize the parts in a cleaning/sanitizing solution
with an active chlorine concentrate of 100 PPM to
200 PPM. Use warm water and follow the
Taylor-approved manufacturer's specifications. If
required by your local code, rinse with clean water.
16. Place the following parts on a clean, dry surface to
air-dry overnight: ice hopper, ice hopper cover,
blender pitchers, splash guard, and ice chute.
17. For machines equipped with the Rinse Station: Place
the Rinse Station assembly (grates, actuator, pivot
rod and rinse pan) on a clean, dry surface to air-dry
overnight.
18. Using the squeeze bottle filled with cleaning
sanitizing solution, flush the ice shaver assembly
while brushing with the large white ice hopper brush.
(
See Figure 6-13.)
Figure 6-13
19. Using the squeeze bottle of cleaning/sanitizing
solution, flush inside, outside, and under the ice
shaver assembly, thoroughly covering all surfaces.
(See Figure 6-14.)
Figure 6-14
To Next Page
