Taylor SB25 User Manual

29
Model SB25
Controls and Systems
Step 7
Remove the cane pump ground lug from the
grounding post.
Step 8
Remove the four (4) screws from the rear of the unit.
Remove the pump assembly.
Figure 38
Step 9
Remove the elbow connection from the pump inlet
by sliding the retaining tab down and pulling out the
elbow.
Figure 39
Step 10
Remove the inner jam nut holding the cane inlet
connector and slide the pump inlet tube and elbow
out through the rear of the unit.
