+ Available Separately, NNN = Not a Service Item, * See Remarks
62
Parts List Model SB25
DESCRIPTION REMARKSWARR.
CLASS
SB25
QTY.
TAYLOR
PART NO.
CABLE-KEYPAD-ISLAND OASIS 081110 1 103 BEZEL-KEYPAD *SB25* 081109-1 1 000
KIT A.-BASE ISLAND OASIS X6519447SV 1 103
SCREW-6-32 X 1/2 HEX HEAD 065194-50 4 000
KIT A.-BOARD-CIRCUIT*C029*DRIV X6519414SV 1 212
FUSE-BOARD-DRIVER-ISLAND OASIS 065194-26 1 000
KIT A.-BRUSH X68468 1 000
BRUSH-MIX PUMP BODY 3" X 7" 023316 1 000 BRUSH-END-DOOR-SPOUT-SS-HT 039719 1 000 BRUSH-TUBE MIX 068460 1 000
KIT A.-ICE BIN-SENSOR X80552 1 103
RETAINER-SWITCH-SAFETY-IO 081123 1 103 SCREW-SENSOR-CLIP-ICE BIN 065194-55 1 000 SENSOR-ICE BIN 065194-53 1 103
KIT A.-MOTOR BLENDER *C029* X6519415SV 1 212
SCREW-6-32X1/2 HEX HEAD 065194-50 6 000
KIT A.-MOTOR SHAVER *C029* X6519416SV 1 212 KIT A.-SEAL SHAFT MOTOR *C029* X6519418SV 1 000 KIT-BLADE-CARTDRIGE*C029*IO 069087 1 000 LABEL-BIN ICE-FILL 067920 1 000 LABEL-CAUTION-GRD-CORD 032165 2 000 LABEL-CAUTION-PERSNL 033161 1 000 LABEL-ISLAND T AYLOR-11X4.9" 082348 1 000 LABEL-ISLAND TAYLOR-8.7X4.9" 082347 1 000 LABEL-WARN-CONDENSER-SHARP 059287 1 000 LABEL-WARN-COVER 051433 * 000 LABEL-WARN-ELEC-SGL-SMALL-CANA 032717-CAN 1 000 LID-POUR-PITCHER *SB25* 081248 2 000 MANIFOLD A.-H2O-SB20-RINSER 082222-05 1 103 RINSE STATION
CAP 082222-125 1 103 W/O-RING COIL-SOLENOID VALVE 24 VDC 082222-051 1 103 W/O-RING ELBOW-STEM-1/4 PTC X 1/4 ST 082222-127 1 103 FILTER-WATER 082222-124 1 000
