Model SB25 Parts List
DESCRIPTION REMARKSWARR.
CLASS
SB25
QTY.
TAYLOR
PART NO.
REGULATOR-WATER-75 PSI FIXED 082222-052 1 103 VALVE-SOLENOID 082222-123 1 103
+BRACKET A.-SOLENOID *SB20* X82582 1 103 +SCREW-10-32X3/8 PHIL PANHD 081205 3 000
MANIFOLD A.-WATER *SB25* 082222-12 1 212
CAP 082222-125 1 103 W/O-RING COIL-SOLENOID VALVE 120 VAC 082222-121 1 103 W/O-RING ELBOW-STEM-1/4 PTC X 1/4 ST 082222-127 1 103 FILTER-WATER 082222-124 1 000 REGULATOR-WATER-15 PSI FIXED 082222-122 1 103 VALVE-SOLENOID 082222-123 1 103
MAN-OPER-IO 081218-M 1 000 MOTOR-BLENDER IO * SEE KIT A.-MOTOR BLENDER MOTOR-SHAVER IO * SEE KIT A.-MOTOR SHAVER MOUNT-MOTOR-SHAVER-ISLAND OASI 081119 1 103 NOZZLE-SPRAY-RINSE *C029* 066814 1 103 RINSE STATION
+GASKET-RINSER NOZZLE-IO 083473 1 000 M4034486 REPLACES 081249 +RING-RETENTION 083459 1 000 M4034486 & UP
NUT-5/16-24 FINISHED HEX JAM 029639-BLK 10 000 NUT-COMPRESSION-.375-WATTS 081246 2 000 NUT-ROD-SUPPORT-ISLAND OASIS 065194-28 8 103 NUT-SCRAMBLER *C088* 081579 1 103
+O-RING-1 OD X .103W 048148 1 000 W/SCRAMBLER
O-RING-.500 OD X .070W 024278 1 000 O-RING-1-7/8OD X .070W 081189 1 000 O-RING-1-3/16OD X .103W-EPDM 081249 * 000 REPLACED BY 083473 GASKET/083459 GASKET-RINSER NOZZLE-IO 083473 1 000 M4034486 REPLACES 081249
+RING-RETENTION 083459 1 000 M4034486
O-RING-3/4 OX X .070W 081888 1 000 O-RING-7/8OD X .139W 081899 2 000 O-RING-1-3/4IDX1-7/8OD 50 DURO 082952 1 000 OVERLAY-KEYPAD *SB25* 082473 1 000 PAN *SB20* 081219 1 103
