TBB Trident - 5.2 Electrical Specifications; 5.3 Protection Features; 5.4 Approvals

bank outputs 12V25A,24V12A & 12V40A, 24V20A – 3 isolated
Nominal battery
voltage
12VDC for 12V models
24VDC for 24V models
Rated DC output
current (total)
12V12A – 12ADC; 12V25A – 25ADC; 12V40A – 40ADC;
24V06A – 6ADC; 24V12A – 12ADC; 24V20A – 20ADC
Charge Algorithms Automatic 6 steps charging curves. Soft start, bulk,
compensation, absorption, floating, recycle.
Nominal input voltage 185-265VAC 50Hz, also can work under 110V input voltage
Charge algorithms Automatic max 6 steps
Battery temperature
compensation
Automatic active when temperature sensor plug in
Absorption and Float
voltage
4 options, please check “4.1 dip switch setting”
Equalize mode
maximum output
voltage
16.5VDC/FREEDOM
Power supply mode
nominal output voltage
13.5+/-0.6 VDC
Efficiency 0.80
PFC >95%
5.3 Protection Features
Reverse Polarity Electronic protect
Battery charger over
temperature
Reduce output power while charger in overtemp condition
Battery over temperature
Battery temperature as sensed by the battery temperature
sensor (if installed) results in charger shutdown at a battery
temperature of 50c
Battery over voltage
limits
Will not start charging if any battery voltage is greater than
15.0VDC
Will not continue charging if any battery voltage is greater
than 16.0VDC
5.4 Approvals
LVD EN60335-1, EN60335-2-29
EMC EN55014-1,EN55014-2,EN61000-3-2,EN61000-3-3
