TC Electronic Finalizer Express - Rear Panel

Main
Power
Switch
Power
Input
Balanced
XLR
analog
Inputs
Balanced
XLR
analog
Outputs
Serial no.
Digital In/Out
AES/EBU
S/PDIF
OPTICAL
(Tos-link)
MIDI
In, Thru, Out
External
Fader
Input
Notes
Pin 2 is “Hot” on all XLR’s (IEC and AES standards)
The Finalizer Express power supply is capable of operating at any line voltage from 100-240 Volts, 50-60Hz.
For further instructions on cables please see our Soldering instructions on page 28-29.
REAR PANEL
8
