25
SMPTE
Device
This parameter selects which Mainframe connected to the
LAN you are working on. Device numbers 1-8, corresponds
to the Device position at the Select page.
Preset Type
Selects whether the preset Event you are working on is a
Scene, Routing, Engine or a System preset.
Bank
Select the bank related to the preset you are about to
setup/recall via SMPTE.
Preset
Select the preset from the selected bank.
File
Current List
Keep
Press to save the Event List locally on the Icon. It is possible
to save one Event List on the Icon. Additional cue-lists can
be stored and recalled on floppy disks on the Mainframe.
The Keep key will turn red as soon as any editing of the list
has taken place, indicating that you must press to save the
list.
This key corresponds/is the same, as the Keep key located
on the Edit page. (see previous page)
Revert
This “Undo” function allows you to revert to the last saved
SMPTE Event list. This is the List that is stored locally on
the TC Icon.
Clear
Press Clear to delete the entire SMPTE Event list present
in the TC Icon.
Remote device disk drive
Event lists can easily be organized and saved to a Floppy
disk in the Mainframe.
Mainframe selection is done in the Auto Edit page.
Get List
Press to get a list of all SMPTE Event lists stored on the
floppy disk located in the Mainframe.
New
Press New to create and name a new Event list in the
floppy disk in the Mainframe.
Save
Press to save the current Event list to the disk.
Load
Press to load Event list from disk.
Delete
Press to delete selected Event preset from the
Event Preset list.
Options
Automation Timecode Options
Master Sync Device
Select which of the Mainframes connected on the LAN you
wish to act as Master Clock.
Start Of Daytime
Range: 23:00:00:.00 or 00:00:00:00
If the SMPTE time code present on your tape media or film
does not start exactly at the beginning of the tape the
23:00:00:00 setting would be a good choice to keep
chronological order in the Event List.
To Next Page
