TC-Helicon GO XLR User Guide

Contents [ hide
1 TC HELICON Sound and Vocal Effects Online Broadcaster Platform
2 Important Safety Instructions
3 Welcome About this document
3.1 GO XLR App
3.2 Download the app
3.3 Get the Reference Manual
4 Controls
5 Connection Diagram
6 Specifications
6.1 Analog Connections
6.2 Controls
6.3 System / Processing
6.4 Power Supply / Voltage
7 FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE
INFORMATION
8 File Downloads
9 References
10 Related Manuals
TC HELICON Sound and Vocal Effects Online Broadcaster Platform
Important Safety Instructions
Terminals marked with this symbol carry electrical current of sufficient magnitude to constitute risk of electric
shock. Use only high-quality professional speaker cables with ¼” TS or twist-locking plugs pre-installed.
All other installation or modification should be performed only by qualified personnel.
This symbol, wherever it appears, alerts you to the presence of uninsulated dangerous voltage inside the
enclosure voltage that may be sufficient to constitute a risk of shock.
This symbol, wherever it appears, alerts you to important operating and maintenance instructions in the
accompanying literature. Please read the manual.
CAUTION:

TC-Helicon GO XLR Specifications

General

Frequency range	10 - 20000 Hz
Channels quantity	- channels
Supported sample rates	48 kHz
Digital sound processing	24 bit
Line Signal-to-Noise Ratio (SNR)	101 dB
Equalizer bands quantity	4
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of microphone inputs	1
DJ mixer	-
Product color	Black
USB connector type	USB Type-B
Fuse	1 A
Phantom power	48 V
Power consumption (typical)	10 W

Weight and Dimensions

Depth	174 mm
Width	285 mm
Height	82 mm
Weight	1550 g
