TC-Helicon VoiceLive 3 Getting Started

Technical specifications
16 VoiceLive3
Technical specifications
Inputs
Voice connector Combo Balanced XLR/
Balanced TRS ¼”phone jack
Input impedance
balanced
3.08kOhm
Mic input level @
0dBFS
-52dBu to +7dBu
Line input level @
0dBFS
-40dBu to +19dBu
EIN @ max mic gain rg
= 150ohm
-127dBu
Mic SNR >100dB at typical Mic Input
gain
A to D conversion 24 Bit, 128 x oversampling
bitstream, 110dB SNR
A-weighted
Guitar connector ¼” phone jack
Guitar input impedance 1 MOhm
Guitar input level @
0dBFS
-2dBU to 14dBu
Guitar input SNR >10 8 d B
A to D conversion 24 Bit, 128x oversampling
bitstream, 110dB SNR
A-weighted
Monitor connector Balanced XLR
Input impedance
balanced
25kOhm
Monitor input level @
0dBFS
+16 d B u
Aux
Aux connector 1/8” stereo mini jack
Aux input level @
0dBFS
+2dBu
Analog outputs
Voice out connectors balanced XLR
Output impedance
balanced/unbalanced
300/150 Ohm
Output range @ 0dBFS Line Level: +14dBu; Mic
Level: -2dBu
Dynamic range >109dB, 20 Hz to 20kHz
Frequency response +0/-0.3dB, 20 Hz to 20kHz
D to A conversion 24 Bit, 128 x oversampling
bitstream, 115dB SNR
A-weighted
Guitar out connectors 1/4” TRS phone jack
Output impedance
balanced/unbalanced
442/221 Ohm
Output range @ 0dBFS Line Level: +14dBu;
Mic Level: - 2dBu
Dynamic range >101dB, 20 Hz to 20kHz
D to A conversion 24 Bit, 128 x oversampling
bitstream, 106dB SNR
A-weighted
Headphone out
Headphone out
connector
1/8” Mini stereo jack, 50
Ohm, +14dBu max
Guitar thru
Buffered guitar input
connector
1/4” TRS phone jack
Output impedance
bal/unbal.
270/540 Ohms
Monitor thru
Direct connection to
monitor input connector
Balanced XLR
Control
USB USB-B, USB-A
MIDI in 5 Pin DIN
Pedal 1/4” TRS phone jack
Power
External power supply 100 to 240 VAC,
50 to 60 Hz (auto-select)
Power consumption < 14 W
Safety
EMC Complies with EN 55103-
1:2009, EN 55103-2:2009,
FCC CFR 47 Part 15B and
ICES-003:2004 4th Ed.
Safety Certified to IEC65, EN
60065, UL6500 and CSA
IEC65, EN 60065, UL6500
and CSA
Operating requirements
Operating temperature 32° F to 122° F
(0° C to 50° C)
Storage temperature -22° F to 167° F
(-30° C to 70° C)
Humidity max. 90 % non-condensing
Size & weight
Dimensions 9” x 4” x 7” (230 x 100 x
180) Weight 5lb. (2.3kg)
Warranty
See for warranty information.

TC-Helicon VoiceLive 3 Specifications

General

Outputs	XLR, 1/4"
MIDI	In/Out
USB	USB for audio I/O and firmware updates
Inputs	XLR, 1/4"
Power Supply	External power supply (included)
