TC-Helicon VoiceLive User Manual

41
GLOBAL EDIT SCREENS
This screen sets the default USER button function. In the preset if the USER button is set to
default, then the USER button assignment will come from this screen.
EDIT 1 knob: U
SER B
UTTON DEFAULT
ASSIGN. Assigns a parameter to be controlled by the User
Button. Options include:
• Harmony Hold
(Not Latching). For a complete description of Harmony Hold see
the Harmony and Tuning section of the manual.
•Tap Tempo
. The LED Displays TAP* - the * flashes the tempo. Please note
that this setting will only have an effect on presets where the delay time source
is set to TAP (see edit screen FX7). Tap tempo will be maintained in VoiceLive
through preset changes. If multiple presets are used in a song with a given
tempo, the delay time only needs to be tapped in once.
• FX Override
– This controls turning on and off the Reverb and Delay effects.
• RevSend Override - Mutes and un-mutes the Reverb sends.
• DlySend Override
- Mutes and un-mutes the Delay sends.
• Bypass Toggle – this is for people who do not like having to hold the harmony
BYPASS button for bypass and would like to do it with a fast click.
• PtchCor Override
–Pitch Correction Enable/Disable.
• Lead V
oice Enable/Disable - Enable/disable the lead voice.
• HrmSolo Override
- Changes the Harm parameter in the CFG1 screen to be
Solo which enables the Harmonies but turns off the Lead Voice.
• Thicken Override Enable/disable thickening
• RoboV
oice - Enables pitch correction and overrides Window, Attack and
Amount parameters to their maximum values which creates the “Cher” effect.
•T
eleVoice All– Takes over the EQ parameters to make the voice sound
telephone like. Affects the lead and harmony voices.
•T
eleVoice Harm– Takes over the EQ parameters to make the harmony voices
sound telephone like. Effects the harmony voices only.
• Moment
ary Harm- Harmonies are enabled only while this button is held.
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
UserBtn Default
UT 2
Radio Voice

TC-Helicon VoiceLive Specifications

Analog Inputs

mic impedance	3.6/1.8 kOhm
line impedance	21/13 kOhm
line input level at 0 dBFS	24 dBu to 0 dBu

Analog Outputs

output impedance	40 Ohm
max output level balanced	20 dBu
max output level unbalanced	14 dBu

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Supplementary

dimensions	11.1" x 10.25" x 3.5" (282 x 260 x 89 mm)
weight	5.9 lb. (2.7 kg)
mains voltage	100 to 240 VAC, 50 to 60 Hz (auto-select)
