TC-Helicon VoiceLive User Manual

42
GLOBAL EDIT SCREENS
EDIT 1 knob: GLOBAL EFFECTS PRESET SELECT. This makes the effect parameters of the chosen
preset global for all recalled presets and Song steps.
EDIT 2 knob: V
IBRATO CONTROL. This sets whether the vibrato follows the onset and attack of the
model (Boost
) or is instantaneous (Manual). The Mod Wheel on most keyboards
controls the vibrato in both modes, boosting the preset value in the Boost
setting
and starting from a value of 0 in the Manual
Setting.
EDIT 1 knob: MIDI C
HANNEL. Sets the base MIDI Send and Receive channel.
EDIT 2 knob: S
YSTEM EXCLUSIVE ID. This parameter sets the MIDI system exclusive ID for
VoiceLive.
EDIT 1 knob: MIDI CC C
ONTROL. On: sends and responds to MIDI CC messages. Off: MIDI CC
messages not sent or responded to.
EDIT 2 knob: G
LOBAL CHORD. Options are as follows:
•On
- The last MIDI detected chord type and root is retained when switching
through chordal presets.
•Of
f - The chord type and root is always taken from the preset recalled.
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
CC-Ctrl GlblChrd
UT 5
On On
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
MidiChan SYXID
UT 4
10
Input Clip
0 PPM dB
-5
-10
Out Clip
-20
-40
HARMONY
THICKEN
EFFECTS
PITCH CORR.
I/O
UTILITIES
MIDI IN
PROGRAM DISPLAY
HARMONY | CORRECTION | EFFECTS
VOICELIVE
VOICE 2
VOICE 4
VOICE 1
VOICE 3
LIMITMIC INGLOBAL FX EDITED
PRESET# HARMONY MODE ROOT SCALE/CHORD
GlbFX VibrtoCtrl
UT 3
Off Boost

TC-Helicon VoiceLive Specifications

Analog Inputs

mic impedance	3.6/1.8 kOhm
line impedance	21/13 kOhm
line input level at 0 dBFS	24 dBu to 0 dBu

Analog Outputs

output impedance	40 Ohm
max output level balanced	20 dBu
max output level unbalanced	14 dBu

Operating Environment

operating temperature	32° F to 122° F (0° C to 50° C)
storage temperature	-22° F to 167° F (-30° C to 70° C)
humidity	Max. 90 % non-condensing

Supplementary

dimensions	11.1" x 10.25" x 3.5" (282 x 260 x 89 mm)
weight	5.9 lb. (2.7 kg)
mains voltage	100 to 240 VAC, 50 to 60 Hz (auto-select)
