TC-Helicon VoiceTone C1 User Manual

Using Multiple VoiceTone Single Pedals
Itispossible(evenencouraged!)tousemorethanoneVoiceTonepedalatatime.Youwillonlyneed
toadjusttheMICGAINcontrolofthefirstpedalinthechain.Ontherest,MICGAINshouldbesetto
the minimum (fully left) position.
Theorderofthepedalsisimportant.Seethefollowingtableshowing2,3and4pedalcombinations.
2Pedals D1>R1 T1>D1 C1>D1 3Pedals T1>D1>R1 T1>C1>R1
  T1>C1 T1>R1 C1>R1  C1>D1>R1 T1>C1>R1
4Pedals T1>C1>D1>R1
The VoiceSupport Application
VoiceSupportisyourwayofgettingthemostfromyourTC-Heliconproduct,aswellaslettingyour
productgrowwithfirmwareupdates.VoiceSupportincludes:
• Accesstofirmwareupdatesandnewfeatures
• Videos,artistprofiles,tips&tricks
• Registrationofyourproduct
To access the VoiceSupport application:
1.DownloadVoiceSupportfromwww.tc-helicon.com/voicesupport.

TC-Helicon VoiceTone C1 Specifications

Input Specifications

mic input impedance	2.68 kOhm
mic input level at 0 dBFS	-42 dBu to +1 dBu
mic input EIN at max mic gain Rg = 150 Ohm	-126 dBu
mic input SNR	>104 dB
guitar input impedance	1 MOhm
guitar input level at 0 dBFS	-7 dBU to 17 dBu
guitar input SNR	>115 dB

Output Specifications

output impedance, balanced/unbalanced	200/100 Ohm
output full scale	+1 dBu
dynamic range	>104 dB, 20 Hz to 20 kHz
frequency response	+0/-0.3 dB, 20 Hz to 20 kHz

Power

power supply (supplied)	12V 0.4A
power consumption	5.6W

Operating Environment

operating temperature	32°F to 122°F (0°C to 50°C)
storage temperature	-22°F to 167°F (-30°C to 70°C)
humidity max.	90% non-condensing

Weight and Dimensions

dimensions	5.4” x 3.5” x 2.3” (140 x 90 x 60)
weight	0.92 lb. (420 g)
