TCL Air Conditioner Service Manual
3. Refrigeration cycle diagram
TIN1
PMV1
TIN2
TIN3
PMV2
PMV3
PMV4
TIN4
T2B1
T2B24
T2B3
T2B4
ST
CONDENSER
liquid
storage
pot
T3
T
TP
HP
COMPRESSOR
Optional
Evaporator
4
