TCL FMA-09CHSD/DVI

TCL Air Conditioner Service Manual
-2
63.74 70.48 77.87
52
6.309 6.655 7.013
106
1.073
1.12 1.168
-1
60.69 67.05 74
53
6.08 6.409 6.748
107
1.042 1.089 1.136
0
57.81 63.8 70.34
54
5.861 6.173 6.495
108
1.013 1.058 1.104
1
55.08 60.72 66.88
55
5.651 5.947 6.253
109
0.9833 1.028 1.074
2
52.49 57.81 63.61
56
5.449 5.73 6.02
110
0.9553 0.9997 1.045
3
50.03 55.05 60.52
57
5.255 5.522 5.798
111
0.9283 0.9719 1.016
4
47.71 52.44 57.59
58
5.07 5.323 5.585
112
0.9021 0.9451 0.9892
5
45.5 49.97 54.82
59
4.891 5.132 5.381
113
0.8765 0.9191 0.9626
6
43.41 47.62 52.2
60
4.72 4.949 5.101
114
0.8524 0.894 0.9367
7
41.42 45.4 49.71
61
4.556 4.774 4.997
115
0.8087 0.8595 0.9117
8
39.53 43.2 42.33
62
4.398 4.605 4.817
116
0.8059 0.8461 0.8875
9
37.74 41.29 45.12
63
4.247 4.448 4.644
117
0.7837 0.8233 0.8641
10
36.04 39.39 43.01
64
4.101 4.288 4.479
118
0.7623 0.8012 0.8413
11 34.42 37.59 41 65 3.961 4.139 4.32 119 0.7415 0.7798 0.8193
12
32.89 35.87 39.1
66
3.827 3.995 4.167
120
13
31.43 34.25 37.29
67
3.698 3.858 4.021
121
0.702 0.7386 0.7773
14
30.04 32.71 35.58
68
122
0.6631 0.7195 0.7572
15
29.72 31.24 33.95
69
123
0.6649 0.7007 0.7378
16
70
3.339
3.476 3.616
124
0.6472 0.6824 0.7189
17
71
3.229
3.359 3.491
125
0.6301 0.6647 0.7006
18
25.13 27.26 29.55
72
3.122 3.246 3.372
126
0.6135 0.6476 0.6829
19 24.05 26.07 28.23 73 3.02 3.138 3.257 127 0.5974 0.6309 0.6657
20
23.02 24.93 26.97
74
2.921 3.033 3.146
128
0.5818 0.6148 0.649
21
22.04 23.84 25.77
75
2.827 2.933 3.04
129
0.5667 0.5991 0.6328
22
21.1 22.81 24.63
76
2.735 2.836 2.938
130
0.5521 0.5839 0.6171
23
20.21 21.83 23.55
77
2.647 2.743 2.84
R—Resistance
Resistance at 25 ℃ :20 kΩ
TH3: Outdoor unit discharge pipe sensor
Befo
re measuring resistance, disconnect connectors as shown above.
51
