MS82MT-AP/LA Chassis Aliment procedure
PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE
16
4.5 ADC Calibration and White Balance Adjustment (automatic)
The process of adjusting ADC and White Balance automatically is out of the range
of this file. Please refer to the relevant technical file of HuiZhou factory of TCL
5. Chip list of software programming before SMT
Following chips must be programmed before SMT by ALL-11 or other tools.
Note:
1) The software for U502 and U702 can be program using ISP tool.
2) Every set has its unique HDCP key which is purchased from suppliers or HDCP
certification authority. Please check HDCP function in the process of production.
3) Once in a while, the software of main board may be upgraded. Please pay attention to
use the latest software before production.
Position Chip type Chip name Part number Software
description
Decal
1 U502 Flash EN25Q32B 13-EN25Q3-2BBEO
main software SO-8
2 U702 E2PROM M24C32MN 13-M24C32-MNB Tcon software SO-8
