TCL TAC-18CSD/XA81I

TCL Air Conditioner Service Manual

61


9.Disassemblytheevaporator
A.Unfix2screwsofleftsideshownas
picture.
B.Unfix2screwsofrightsideonmotor
cover/rightsupportplate. 
C.Taketheevaporatoroutfromunitby
uplifting the IUPUT/OUTPUT pipes
slightly.


螺钉
螺钉/卡扣



10.RemovetheMOTORCOVER
Unfix4screwsonthemotorcoverwith
baseframe.



螺钉



11.Disassemblyfanmotorandfanblade.
A. Uplift the fan blade and fanmotor,
takethebaseframeout.

B.Unfixonescrewontheaxisoffan
motor, and you can get fan blade and
fanmotorseparately. 





螺钉
screws Screws+motor
cover

screws
screw
