4. Disassembly IDU & ODU
4.1. IDU Disassembly
Steps Referencephoto
1. Beforedisassembly
Theorginalstatus.

2.Disassemblyfrontpanel,displayboardandWIFImodule.
A.Openfrontpanel.
B.Removeonescrewandtakethedispl
a
boxoutfromthepanel.
C.Releasepanelaxiswhichshowninr
e
arrows out from middle frame and ta
k
thepanelout.
D.UnscrewandtaketheWIFImoduleo
u
frommiddleframe.


显示盒
WiFi模块


3.Removethelouver.
Unlock the louver lockers (clip), bend
the louver slightly by hands and
remove it out from middle frame and
steppingmotor.


导风板转轴插销
导风板
拆卸插销


WIFIModule
Louverlocker
Louver
Unlockthelocker
Displaybox
