TCL Air Conditioner Service Manual
67
step11Remove the fan motor and fan supporter.
Unfix screws btw fan
motor with
supporter, and
supporter with base
plate.
Note:
Pay attention to the
motor wiring, it can’t
be taken out by
force.
