TCL TACM2O-28HIA User Manual

Air Conditioner Service Manual
31
OUTDOOR UNIT- TACM2O-18HIA
No.
Part No.
Part Name
Q’ty
Remark
1
210701820
Grille
1
2
210800251
Top cover
1
3
231235682
Condenser
1
4
1080050130
Outdoor motor supporter
1
5
210900219
Outdoor motor
1
6
1070030054AA
Propeller fan
1
7
1081990053
Left grille supporter
2
8
210800250
Front plate
2
9
210701513
Fan guard
1
10
211232717
Compressor and accessories
1
11
1120110016A
4-way valve
1
12
231235803
4-way valve assembly
1
13
210800281
Base
1
14
210800252C
Right plate
1
15
231202639
Two-way valve
2
16
230802035
Valve supporter
1
17
3120120048
Three-way valve
2
18
1070350971
Electrical box cover
1
19
230701494
Cable clamp
1
20
230901989A
Terminal
1
1170200041C
Terminal
1
21
230904195
Outdoor PCB assembly
1
22
1170190004
Inductor
1
23
231235632
Electronic expand valve
1
24
234144007
Partition plate
1
25
1170230027A
Pipe Temp. sensor and
outdoor Temp. sensor
1
Not shown in explosion view
26
1170230006A
Discharge Temp. sensor
1
27
210901787
Expand valve in and out
Temp. sensor
1
28
210901784A
Suction Temp. sensor
1
29
211306934
Base carton
1
30
211306938XS
Cabinet carton
1
31
211306722
Base foaming
1
32
211306721
Cover foaming
1
