TCL TACM2O-28HIA

Air Conditioner Service Manual
32
OUTDOOR UNIT- TACM3O-21HIA
No.
Part No.
Part Name
Q’ty
Remark
1
1071990041
Grille
1
2
1080020023
Top cover
1
3
231235780
Condenser
1
4
1080050112
Outdoor motor supporter
1
5
1170040166D
Outdoor motor
1
6
1070030059
Propeller fan
1
7
1081990040
Left grille supporter
1
8
1080050103
Front plate
1
9
1080050105
Fan guard
1
10
211232717
Compressor and accessories
1
11
1120500226A
4-way valve
1
12
231235750
4-way valve assembly
1
13
210800795
Base
1
14
230803016
Right plate
1
15
231202639
Two-way valve
3
16
3087170101
Valve supporter
1
17
1120130039
Three-way valve
2
3120120048
Three-way valve
1
18
230700661
Electrical box cover
1
19
210735991
Cable clamp
1
230701493
Cable clamp
1
20
230901989A
Terminal
1
1170200041C
Terminal
1
1170200039A
Terminal
1
21
230904196
Outdoor PCB assembly
1
22
230900333
Inductor
1
23
231235767
Electronic expand valve
1
24
230803541
Partition plate
1
25
1170230027A
Pipe Temp. sensor and
outdoor Temp. sensor
1
Not shown in explosion view
26
1170230006A
Discharge Temp. sensor
1
27
210901786
Expand valve in Temp.
sensor
1
28
210901786A
Expand valve out Temp.
sensor
1
29
210901784
Suction Temp. sensor
1
30
1190030009
Base carton
1
31
1190042096XL
Cabinet carton
1
32
1151990016C
Base foaming
1
33
1151990018
Cover foaming
1
