TCL TACM2O-28HIA

Air Conditioner Service Manual
33
OUTDOOR UNIT- TACM4O-28HIA
No.
Part No.
Part Name
Q’ty
Remark
1
1071990041
Grille
1
2
230800156
Top cover
1
3
231235638
Condenser
1
4
230801220
Outdoor motor supporter
1
5
230901010
Outdoor motor
1
6
230700625
Propeller fan
1
7
230801134
Left grille supporter
2
8
234102065
Front plate
2
9
210702363
Fan guard
1
10
211205870
Compressor and accessories
1
11
1120500226A
4-way valve
1
12
231235684
4-way valve assembly
1
13
230801174
Base
1
14
230803560
Right plate
1
15
231202639
Two-way valve
4
16
230803603
Valve supporter
1
17
3120120048
Three-way valve
4
18
230700661
Electrical box cover
1
19
210735991
Cable clamp
1
230701493
Cable clamp
1
20
230901989A
Terminal
1
1170200041C
Terminal
1
1170200041D
Terminal
1
21
230904197
Outdoor PCB assembly
1
22
230900333
Inductor
1
23
231235806
Electronic expand valve
1
24
230803537
Partition plate
1
25
1170230027A
Pipe Temp. sensor and
outdoor Temp. sensor
1
Not shown in explosion view
26
1170230026A
Discharge Temp. sensor
1
27
210901785
Expand valve in Temp.
sensor
1
28
210901785A
Expand valve out Temp.
sensor
1
29
210901784
Suction Temp. sensor
1
30 231303922BD
Cabinet carton
1
