TCL U-MATCH-R32 SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL
Ceiling & Floor
Type
TCC-12ZHRH/DV(02)
TCC-18ZHRH/DV(02)
12500/13500
18000/19500
220-240V～
1ph 50Hz
TCC-24ZHRH/DV(02)
24000/26000
220-240V～
1ph 50Hz
TCC-30ZHRH/DV(02)
30000/32000
220-240V～
1ph 50Hz
TCC-36ZHRH/DV(02)
36000/39600
220-240V～
1ph 50Hz
TCC-42ZHRH/DV(02)
42000/46000
220-240V～
1ph 50Hz
TCC-48ZHRH/DVI(02)
48000/55000
220-240V～
1ph 50Hz
TCC-55ZHRH/DVI(02)
52000/62000
220-240V～
1ph 50Hz
2.2 Outdoor Units
Model Name
Power Supply (V, Ph, Hz)
Appearance
TCC-18HRH/DVO(02)
TCC-12HRH/DVO(02)
220-240V～1ph 50Hz
TCC-24HRH/DVO(02)
220-240V～1ph 50Hz
TCC-30HRH/DVO(02)
220-240V～1ph 50Hz
TCC-36HRH/DVO(02)
220-240V～1ph 50Hz
TCC-36HRH/DV7O(02)
380-415V～3ph 50Hz
TCC-42HRH/DVO(02)
220-240V～1ph 50Hz
TCC-42HRH/DV7O(02)
380-415V～3ph 50Hz
