TCL U-MATCH-R32 SERIES DC INVERTER AIR CONDITIONERS SERVICE MANUAL
205
Eb
PCB and display screen communication failure
12
Hardware Error
EC
Outdoor modules Communication failure
13
Hardware Error
EE
Outdoor EEPROM fault
14
Hardware Error
EF
Outdoor DC fan failure
15
Hardware Error
EH
Outdoor suction sensor failure
16
Hardware Error
EP
Outdoor compressor casing top failure
17
Hardware Error
EU
Outdoor voltage sensor failure
18
Hardware Error
Ej
Outdoor central coil temperature sensor failure
30
Hardware Error
En
Outdoor air pipe temperature sensor failure
31
Hardware Error
Ey
Outdoor liquid pipe temperature sensor failure
32
Hardware Error
P0
IPM module protection
19
Others Error
P1
Overvoltage and undervoltage protection
20
Others Error
P2
Overcurrent protection
21
Others Error
P3
Other protections
22
Others Error
P4
Protection against excessive outdoor exhaust
temperature
23
Others Error
P5
Cooling protection against overcooling
24
Others Error
P6
Cooling and anti overheating protection
25
Others Error
P7
Heating and anti overheating protection
26
Others Error
P8
Protection against high or low outdoor temperature
27
Remote control display
adjustment
P9
Compressor drive protection ( abnormal load)
28
Others Error
PA
Communication failure/ mode conflict
29
Others Error
F0
Infrared human sensing sensor failure
33
Remote control display
adjustment
F1
Battery module failure
34
Remote control display
adjustment
F2
Exhaust temperature sensor failure
protection
35
Others Error
F3
Failure protection of outer tube
temperature sensor
36
Others Error
F4
Abnormal protection of refrigerant
circulation
37
Others Error
F5
PFC protection
38
Others Error
F6
Compressor missing/ reverse phase protection
39
Others Error
F7
Module temperature protection
40
Others Error
F8
Abnormal commutation of four- way valve
41
Others Error
F9
Module temperature sensor circuit malfunction
42
Hardware Error
