45
17.7 1ψZero crossing control (By TRIAC)
z Available Models： uTC92 / uPC92，uTC72 / uPC72
uTC52 / uPC52
z OUT1: 1ψSSR
z Data Change： OUTY=0
CYT1=1
Short
Controller
G1
G2
PROT
T1
G1
S
R
UV
TRIAC
T2
Load
Fast Fuse
