Page 23
Description
Qty
700-40 700-45
SP SPA SPD IP IC AF SPA SPD
1 Round Head Screw 10 1-128279 1-128279 1-128279 1-128279 1-128279 1-128279 1-128279 1-128279
2 Adjuster Assembly 1 700100 700100 700100 700100 700100 700100 700100 700100
3 Drive Shaft 1 700719 700719 700019 700719 700719 700019 700719 700019
4 E-Ring 1 700016 700016 700016 700016 700016 700016 700016 700016
5A Acetal Face Gear, 2:1 Packing 1 700018 700018 700018 700018 700018 700018 700018 700018
5B Acetal Face Gear; 1:1 Packing 1 700048 700048 700048 700048 700048 700048 700048 700048
6 Acetal Bushing 2 700020 700020 700020 700020 700020 700020 700020 700020
7 Adjuster Cover Plate 1 700617 700617 700617 700617 700617 700617 700617 700617
8 Seal Wire 1 1-118849 1-118849 1-118849 1-118849 1-118849 1-118849 1-118849 1-118849
9 Drilled Head Screw 2 700042D 700042D 700042D 700042D 700042D 700042D 700042D 700042D
10 Drive Shaft Retainer 1 700022 700022 700022 700022 700022 700022 700022 700022
11 Head Mount Screw 4 700040 700040 700040 700040 700040 700040 700040 700040
12 Register Support 1 700201 700201 700211 700201 700201 700211 700201 700211
13 Packing Retaining Plate 1 700015 700015 700015 700015 700015 700015 700015 700015
14A 2:1 Packing Capsule Assy. 1 700150 700150 700155 700155 700155 700155 700150 700155
14B 1:1 Packing Capsule Assy. 1 700170 700170 700175 700175 700175 700175 700170 700175
15 Packing O-Ring 1 700009 700009 700010 700010 700010 700009 700010 700009
16 Plug 2 700024 700024 700024 700024 700024 700024 700024 700024
17 Front Cover 1 706500 706500 704503 706500 706500 704503 706500 704503
18A Cap Screw 18 704016 704016 704016 704016 704016 704016 704016 704016
19 Rear Cover 1 704550 704550 704553 704550 704550 704553 704550 704553
20 Round Head Screw 16 704014 704014 704014 704014 704014 704014 704014 704014
21 Bearing Plate 2 704230 704235 704235 704230 704225 704225 704225 704225
22 Cover O-Ring 2 704001 704001 704071 704002 704002 704002 704001 704071
23 Housing 1 704110 704110 704113 704110 704110 704113 704110 704113
24 Flat Washer 8 704018 704018 704018 704018 704018 704018 704018 704018
25A Cap Screw 4 704017 704017 704017 704017 704017 704017 704017 704017
26A Flange; 4” NPT 2 704600 704600 704613 704600 704600 704613 704600 704613
27 Flange O-Ring 2 704012 704012 704072 704013 704013 704013 704012 704072
28 Blocking Rotor Gear 1 704351 704351 704350 704351 704351 704350 704350 704350
29 Rotor Lock Nut 3 704010 704010 704010 704010 704010 704010 704010 704010
30 Displacement Rotor Gear 2 704451 704451 704450 704451 704451 704450 704450 704450
31 Rotor Key 3 704008 704008 704008 704008 704008 704008 704008 704008
32 Displacement Rotor 2 704405 704405 704422 704410 704410 704425 704405 704422
33 Blocking Rotor 1 704305 704305 704322 704310 704310 704325 704305 704322
34 Lock Washer 4 700071 700071 700071 700071 700071 700071 700071 700071
18B Drilled Cap Screw 4 704016D 704016D 704016D 704016D 704016D 704016D 704016D 704016D
25B Drilled Cap Screw 4 704017D 704017D 704017D 704017D 704017D 704017D 704017D 704017D
26B Flange; 4” BSPT 2 704603 704603 704812 704603 704603 704812 704603 704812
700-40 / 700-45 Meter Assembly
Meter Cold Weather Seal Kit—TCS 704078
Contents:
(15) Packing O-Ring Qty. 1
(22) Housing O-Ring Qty. 2
(27) Flange O-Ring Qty. 2
All seals are low temperature Nitrile Rubber
