TCS 700-40 - Hydraulic Preset Valve Assembly

TCS900004, Rev.4
07/12/2016
Check us out at www.TCSmeters.com
Page 27
750-40 Hydraulic Preset Valve Assembly
Item Description Qty
SP IP SPD
1 Linkage Assembly Kit 1 754062KT 754062KT 754062KT
2 Seal Kit 1 754314KT 754314KT 754314KT
3 Flat Washer 4 754013 754013 754013
4 Cap Screw 2 754012 754012 754012
5 Drilled Cap Screw 2 704017D 704017D 704017D
6 Valve Cover 1 754015 754015 754018
7 Shaft 1 754008 754008 754008
8 Lever Arm Shaft 1 754005 754005 754005
9 Spring Pin 1 754022 754022 754022
10 Lever 1 754023 754023 754023
11 Flat Washer 4 754024 754024 754024
12 Cotter Pin 4 754037 754037 754037
13 Swivel Pin 2 754027 754027 754027
14 Internal Valve Spring 1 754019 754019 754019
15 Cover Gasket 1 704012 704013 704072
16 Piston 1 754020 754020 754020
17 Flat Washer 1 754028 754028 754028
18 Snap Ring 1 754029 754029 754029
19 Valve Body 1 754040 754040 754043
20 Upper Seal 1 754035 754036 754035
21 Lower Seal 1 754033 754034 754033
22 Piston Guide 1 754030 754031 754030
23 Gasket 1 704022 704022 704022
24 Screw 2 754004 754004 754004
750-40
25 Cap Screw 1 753112 753112 753112
26 Operating Lever 1 754110 754110 754110
27 Washer 1 750035 750035 750035
28 Nut 1 750037 750037 750037
29 E-Ring 1 750004 750004 750004
30 Lever Knob 1 753052 753052 753052
Valve Cold Weather Seal Kit—TCS 754078 All seals are low temperature Nitrile Rubber, FKM or PTFE
Contents:
(21) Lower Seal Qty. 1 (20) Upper Seal Qty. 1
(*) Flange O-Ring Qty. 2 (15) Cover Seal Qty. 1
(*) Shaft Seal Qty. 2 (*) Top Seal Qty. 2
(*) - Items replace components from item 2
