TCS 700-40 - Air Eliminator Strainer Assembly (Continued)

TCS900004, Rev.4
07/12/2016
Check us out at www.TCSmeters.com
Page 25
740 Air Eliminator / Strainer Assembly
Item Description Qty
740-40
SP SPD IP AF
1A Cap Screw 8 740050 740050 740050 740050
2 Ring Washer 12 740051 740051 740051 740051
3A Outlet Cover, NPT 2 740010 740016 740010 740016
4 Valve Plate 2 740205 - - -
5 Screw 6 740030 740030
740030
740030
6 Split Lock Washer 2 740017 740017
740017
740017
7 Cap Screw 2 701017 700054 701017 700054
8 Flat Washer 4 702018 702018 702018 702018
9 Air Eliminator Housing 1 740020 740022 740020 740022
10 Plug 1 2-126146 2-126146 2-126146 2-126146
11 Retaining Clip 2 740012 740012 740012 740012
12 PTFE Reed Seal 2 - 740077 740077 740077
13 Float Assembly 1 740013 740013 740013 740013
14 Diffuser and Shaft Assembly 1 740035 740035 740035 740035
15 Top Seal O-Ring 1 740009 740019 740019 740019
16 Strainer Housing 1 744021 744023
744021
744023
17A 0.050P Strainer Basket; STD 1 - -
744005
744005
17B 40M Strainer Basket; STD 1 744010 744010 - -
17C 80M Strainer Basket 1 744015 744015 - -
17D 100M Strainer Basket 1 744025 744025 - -
18 Seal Ring 1 744003 744004 744004 744004
19 Basket Cover; STD 1 744050 744053 744050 744053
20 Basket Cover; Two 1/2” NPT Ports 1 744055 744256 744055 744256
21 3/8” x 1/2” NPT Thermowell 1 740305 740405 740305 740405
24 Plate Seal 4 - 740004
740004
740004
25 Valve Plate 2 - 740076
740076
740076
26 Valve Plate Kit 2 - 740106 740106 740106
27 1/2” x 1/2” NPT Thermowell 1 740300 740400 740300 740400
23 Reed Valve 2 740007 740007 740007 740007
22 Strainer Cover; Optional 1 740041 740042 740041 740042
28A Cap Screw 2 704027 704027 704027 704027
29 Flat Washer 4 704018 704018 704018 704018
30 Flange O-Ring 1 704012 704013 704013 704013
31 Basket Cover; One 1/2” NPT Port 1 744155 744156 744155 744156
1B Drilled Cap Screw 4 740050D 740050D 740050D 740050D
7B Drilled Cap Screw 2 701017D 701017D 701017D 701017D
28B Drilled Cap Screw 2 704027D 704027D 704027D 704027D
3B Outlet Cover, BSPT 2 740710 740716 740710 740716
Strainer Cold Weather Seal Kit—TCS 744078 Contents:
All seals are low temperature Nitrile Rubber (4) Top Seal Qty. 1
(8) Seal Ring Qty. 1
(14) Flange O-Ring Qty. 2
