TCS 700-40 - Hydraulic Preset Valve Assembly; Torque Specifications

TCS900004, Rev.4
07/12/2016
Check us out at www.TCSmeters.com
Page 28
This Torque Chart is for 18-8 Stainless Steel Bolts
**Values can be +/- 10% of value listed**
Torque Specifications
700-40/45 METER ASSEMBLY
Part Number
& Description
Tool
Foot Lbs. Newton Meter
Unlubricated Unlubricated
TCS 704016
Cover Screws
9/16” hex
wrench/socket
3/8-16 UNC 2B 19.7 11.8 26.7 16.0
TCS 700040
Counter Support
7/16” hex
wrench/socket
1/4-20 UNC 2B 6.3 3.8 8.5 5.2
TCS 704014
Bearing Plate
slotted
screwdriver
1/4-20 UNC 2B 6.3 3.8 8.5 5.2
TCS 1-128279
Dust Cover
slotted
screwdriver
10-24 UNC-2B 1.9 1.1 2.6 1.5
TCS 704010
Rotor Gear
1-1/4” hex
wrench/socket
7/8-14 193.2 115.9 261.9 157.1
Bolt/Nut Size
Lubricated Lubricated
740-40 AIR ELIMINATOR/STRAINER ASSEMBLY
Part Number
& Description
Tool Bolt/Nut Size
Foot Lbs. Newton Meter
Unlubricated Lubricated Unlubricated Lubricated
TCS 740050
Cover Plate
1/2” hex screw
wrench/socket
5/16-18 UNC 2B 11 6.6 14.9 8.9
TCS 704017
Cap Screws
15/16” hex
wrench/socket
5/8-11 UNC 2B 92.5 55.5 125.4 75.2
TCS 740030
Reed & Diffuser
slotted
screwdriver
8-32 UNC 2B 1.65 1.0 2.2 1.4
Part Number
& Description
Tool Bolt/Nut Size
Foot Lbs. Newton Meter
Unlubricated Lubricated Unlubricated Lubricated
TCS 754012
Cap Screw
15/16” hex
wrench/socket
5/8-11 UNC 2B 92.5 55.5 125.4 75.2
TCS 704017
Cap Screws
15/16” hex
wrench/socket
5/8-11 UNC 2B 92.5 55.5 125.4 75.2
TCS 754004
Guide Screw
1/8”
Allen wrench
10-24 UNC 2B 1.9 1.1 2.6 1.5
750-40 HYDRAULIC PRESET VALVE ASSEMBLY
