1 Inspection Initial physical inspection of the power supply Section 3.3
2 Installation
Installing the power supply, Ensuring adequate
ventilation.
Section 3.4
Section 3.5
3 AC source AC source requirements
Connecting the power supply to the AC source.
Safety instructions
Section 3.6
4 Test Turn-on checkout procedure. Section 3.7
5 Load connection Wire size selection. Local /Remote sensing. Single or
multiple loads.
Section 3.8
6 Default setting The power supply setting at shipment. User Manual
Table 3-1: Basic Setup Procedure
3.3
Initial Inspection
Prior to shipment this power supply was inspected and found free of mechanical or electrical defects.
Upon unpacking of the power supply, inspect for any damage which may have occurred in transit. The
inspection should confirm that there is no exterior damage to the power supply such as broken knobs
or connectors and that the front panel and meter faces are not scratched or cracked. Keep all packing
material until the inspection has been completed. If damage is detected, file a claim with carrier
immediately and notify the TDK-Lambda sales or service facility nearest you.
3.4
Rack Mounting
The ™ power supply series is designed to fit in a standard 19” equipment rack.
3.4.1
Install the Power Supply in a Rack
1. Use the front panel rack-mount brackets to install the power supply in the rack.
2. Use a support bar to provide adequate support for the rear of the power supply. Do not obstruct
the air exhaust at the rear panel of the Unit.
