5.5.3 Output control
#
Commands
1 :VOLn;
2 :VOL!;
Description
Sets the output voltage value in volts. This programmed voltage is the
actual output at constant-voltage mode or the voltage limit at constant
current mode. The range of the voltage values are as shown in table 5-1.
Use all digits for voltage programming
Returns the string (Set Voltage) followed by the present programmed
output voltage value. The actual voltage range is as shown in table 5-1.
example: SV5.010 SV08.500
SV
Note:
The ZUP can accept programmed value
higher by up to 5% than the table values,
however it is not recommended to program
power supply over the rated voltage.
Table 5-1: Voltage programming range.
Example - ZUP6-XY :VOL5.010; ZUP10-XY :VOL08.500;
Example-ZUP60-3.5 :CUR3.000; ZUP10-40 :CUR07.50;
Model MIN.
MAX.
ZUP6-XY 0.000
6.000
ZUP10-XY 00.000
10.000
ZUP20-XY 00.000
20.000
ZUP36-XY
ZUP80-XY
00.00
00.00
36.00
80.00
ZUP60-XY
ZUP120-XY
00.00
000.00
60.00
120.00
4 :CURn;
3 :VOL?;
Sets the output current in Ampers. This programmed current is the actual
output current at constant-current mode or the current limit at constant
voltage mode. The programming range is shown in table 5-2:
Use all digits for current programming.
Returns the string (Actual Voltage) followed by the actual output voltage.
The actual voltage range is the same as the programming range.
example: AV5.010 AV08.500
AV
Note:
The ZUP can accept values higher by 5%
than the rating. It is recommended to set the
output current to 105% of the rating if the
unit is required to supply the rated current.
Model MIN.
MAX.
ZUP6-33 00.00
33.00
ZUP6-66 00.00
66.00
ZUP6-132 000.00
132.00
ZUP10-20 00.000
20.000
ZUP10-40
ZUP10-80
ZUP20-10
ZUP20-20
ZUP20-40
ZUP36-6
ZUP36-12
00.00
00.00
00.000
00.000
00.00
0.000
00.000
40.00
80.00
10.000
20.000
40.00
6.000
12.000
ZUP36-24
ZUP60-3.5
ZUP60-7
ZUP60-14
00.000
0.000
0.000
00.000
24.000
3.500
7.000
14.000
ZUP80-2.5
ZUP80-5
ZUP120-1.8
ZUP120-3.6
0.0000
0.000
0.0000
0.000
2.5000
5.000
1.8000
3.600
Table 5-2: Current programming range.
