REMOVE BATTERY DOOR SCREWS
3. USE A TORX HEAD (size T-6)
SCREWDRIVER TO REMOVE 6
SCREWS
4. USE FLATHEAD SCREWDRIVER
TO PRY LID FROM HOUSING. THE
DOOR IS AFFIXED TO THE
HOUSING WITH ADHESIVE TAPE.
5. REMOVE DOOR AS SHOWN
