7
LOCATION OF CONTROLS (CONTINUED)
1 2 3 4 5 6
REAR
1. DC IN Jack 18V z
(AC ADAPTER PART
NO. 151-UGPE30200-E*)
2. USB Jack
(USB CABLE PART
NO. 174-9USBBGBW-E*)
3. RCA IN Jacks
4. LINE IN Jack
5. INST (Instrument) Jack
6. Battery Compartment
(Bottom of Unit)
(BATTERY COVER PART
NO. 309-ABS-05134-0BAE*
BATTERY SCREW PART
NO. 353-0607176-E*)
*Consumer Replaceable Part (See page 24 to order.)
