TDW PIG-SIG V User Manual

37
Section IV – Pipeline Under Pressure
2.0 Installation
Figure 4.28. Crank Handle.
Figure 4.29. Mark on Body Tube
IMPORTANT
If the TOTAL SET distance cannot be attained, the
PIG-SIG V may not be completely set. DO NOT
REMOVE VALVE. Check all measurements. If the
plug needs to be removed, follow the removal
instructions, check all work including measurements,
and reset.
If the chips are stopping the plug from being set,
remove the machine and remove the THREAD-O-
RING plug holder.
