2-1.SPECIFICATIONS
MECHANCAL—————
TYPE:
a)
4
track
4
channel
stereophonic
b) 4 track 2 channel stereophonic
c) 4 track 1 channel monophonic
HEAD:
Erase
head
x
1,
Record
head
x
1,
Playback
x
1
REEL SIZE: 10-1/2" maximum NAB reel
TAPE WIDTH: Standard 1/4 inch tape
TAPE SPEED: 15ips and 7-1/2ips (0.52)
MOTORS:
6
pole
eddy
current
motors
for
reel
drive
x
2
4/8 pole hysteresis synchronous capstan motor x 1
WOW AND FLUTTER: 0.15% at 15ips (RMS)
0.18% at 7-1/2ips (RMS)
Wow and flutter measured according to unweighted
(RMS) NAB standard using TEAC YTIT-2003/2004
flutter free tape. Above value is measured
during playback.
FAST
WINDING
TIME:
Approx.
140
seconds
or
less
with
1800
ft
tape
OPERATING
POSITION:
Horizontal
or
vertical
POWER REQUIREMENT: DM : 100V 50 Hz, 60 Hz
TCA:
117V/60
Hz
for
TEAC
CORPORATION
OF
AMERICA
WEIGHT:
49.5
lbs
(22.5kg)
net
DIMENSIONS:
AEN Hy
' |
:
i pec te — gi
(45mm) (90mm) (35mm)!
i 6g ———-4
1-174
(70mm)
Fig. 2-1 Dimensions A-3340S
