−6−
EXPLODED VIEW LIST
REF.NO. PARTSNO. DESCRIPTION REMARKS
40 E903141130010 TUNER,FM/AMKST‑MB014MA1‑13[E,A]
E903111300010 TUNER,FM/AMKST‑MB001MA1‑13[CN]
E903011300010 TUNER,FM/AMKST‑MB001MA0‑13S[K]
41 7028063232020 COMPONENTPCBASSY
42 G606030164010 TERMINAL,RCA3PIN
43 3207211466030 CHASSIS,BACK[E]
3207211466060 CHASSIS,BACK[A]
3207211466050 CHASSIS,BACK[CN]
3207211466040 CHASSIS,BACK[K]
44 3007210356000 CABINET,TOP[E,A,K]
3007210356010 CABINET,TOP[CN]
45 7028063231050 ST‑BYPCBASSY[E]
7028063231080 ST‑BYPCBASSY[A]
7028063231070 ST‑BYPCBASSY[CN]
7028063231060 ST‑BYPCBASSY[K]
46£ G435040110000 SOCKET,POWERRECEPTACLE[E]
£ G435000130010 SOCKET,POWERRECEPTACLE[CN]
£ G435000160010 SOCKET,POWERRECEPTACLE[K]
47£ G430040550010 SOCKET,POWERAC
48 2410040353010 BUSHING,TERMINAL[E,A,K]
49£ L061000000060 CORD,AC[E]
£ L068020130010 CORDASSY[A]
£ L061000000040 CORD,AC[CN]
£ L061000000050 CORD,AC[K]
50£ 8200960610260 POWERTRANS,MAIN230V[E,A]
£ 8200960610270 POWERTRANS,MAIN220V[CN,K]
N712151634810 CABLE,FLATCARD15P
N712172044810 CABLE,FLATCARD17P
Q204C J503947F00000 TR,2SD947F
Q204FL J503947F00000 TR,2SD947F
Q204FR J503947F00000 TR,2SD947F
Q204SB J503947F00000 TR,2SD947F
Q204SL J503947F00000 TR,2SD947F
Q204SR J503947F00000 TR,2SD947F
Q205C£ J5032390Y0000 TR,2SD2390Y
Q205FL£ J5032390Y0000 TR,2SD2390Y
Q205FR£ J5032390Y0000 TR,2SD2390Y
Q205SB£ J5032390Y0000 TR,2SD2390Y
Q205SL£ J5032390Y0000 TR,2SD2390Y
Q205SR£ J5032390Y0000 TR,2SD2390Y
Q206C£ J5011560Y0000 TR,2SB1560Y
Q206FL£ J5011560Y0000 TR,2SB1560Y
Q206FR£ J5011560Y0000 TR,2SB1560Y
Q206SB£ J5011560Y0000 TR,2SB1560Y
Q206SL£ J5011560Y0000 TR,2SB1560Y
Q206SR£ J5011560Y0000 TR,2SB1560Y
