Teac AG-7D - Amp Pcb Assy

−17−
MAIN PCB ASSY [K]
REF.NO. PARTSNO. DESCRIPTION
R517£ C1012R2064060 R,FUSIBLEMETAL2.2J1/2W
R518£ C060010165060 R,METAL100J1W
R519£ C060010165060 R,METAL100J1W
RLY300 G680120502040 RELAY,G5PA‑28‑NWDC12V
RLY301 G680120502040 RELAY,G5PA‑28‑NWDC12V
RLY302 G680120502040 RELAY,G5PA‑28‑NWDC12V
XTAL501 E830100000060 RESONATOR,CERAMIC
AMP PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
7028063261010 AMPPCBASSY
7020063260000 AMPPCB
CP204 L101220040000 CNWAFER,G1L‑S‑4P‑S2T2‑EF
CP205 L101220150000 CNWAFER,GIL‑S‑15P‑S2T2‑EF
D201C K000013300520 D,1SS133T‑72
D201FL K000013300520 D,1SS133T‑72
D201FR K000013300520 D,1SS133T‑72
D201SB K000013300520 D,1SS133T‑72
D201SL K000013300520 D,1SS133T‑72
D201SR K000013300520 D,1SS133T‑72
D203 K000013300520 D,1SS133T‑72
L201C D330900001320 COIL,FILTER‑INDUCTORJ9000031
L201FL D330900001320 COIL,FILTER‑INDUCTORJ9000031
L201FR D330900001320 COIL,FILTER‑INDUCTORJ9000031
L201SB D330900001320 COIL,FILTER‑INDUCTORJ9000031
L201SL D330900001320 COIL,FILTER‑INDUCTORJ9000031
L201SR D330900001320 COIL,FILTER‑INDUCTORJ9000031
Q201C J5000992F0050 TR,KSA992F
Q201FL J5000992F0050 TR,KSA992F
Q201FR J5000992F0050 TR,KSA992F
Q201SB J5000992F0050 TR,KSA992F
Q201SL J5000992F0050 TR,KSA992F
Q201SR J5000992F0050 TR,KSA992F
Q202C J5000992F0050 TR,KSA992F
Q202FL J5000992F0050 TR,KSA992F
Q202FR J5000992F0050 TR,KSA992F
Q202SB J5000992F0050 TR,KSA992F
Q202SL J5000992F0050 TR,KSA992F
Q202SR J5000992F0050 TR,KSA992F
Q203C J5021845F0000 TR,KSC1845F
Q203FL J5021845F0000 TR,KSC1845F
Q203FR J5021845F0000 TR,KSC1845F
Q203SB J5021845F0000 TR,KSC1845F
Q203SL J5021845F0000 TR,KSC1845F
Q203SR J5021845F0000 TR,KSC1845F
Q207C J5021845F0000 TR,KSC1845F
Q207FL J5021845F0000 TR,KSC1845F
Q207FR J5021845F0000 TR,KSC1845F
Q207SB J5021845F0000 TR,KSC1845F
Q207SL J5021845F0000 TR,KSC1845F
Q207SR J5021845F0000 TR,KSC1845F
Q208 J6020107M0010 TR,KRC107M
AMP PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
R216C£ C060056265050 R,METAL5.6KJ1W
R216FL£ C060056265050 R,METAL5.6KJ1W
R216FR£ C060056265050 R,METAL5.6KJ1W
R216SB£ C060056265050 R,METAL5.6KJ1W
R216SL£ C060056265050 R,METAL5.6KJ1W
R216SR£ C060056265050 R,METAL5.6KJ1W
R217C£ C060056265050 R,METAL5.6KJ1W
R217FL£ C060056265050 R,METAL5.6KJ1W
R217FR£ C060056265050 R,METAL5.6KJ1W
R217SB£ C060056265050 R,METAL5.6KJ1W
R217SL£ C060056265050 R,METAL5.6KJ1W
R217SR£ C060056265050 R,METAL5.6KJ1W
R220C£ C060R22065050 R,METAL0.22J1W
R220FL£ C060R22065050 R,METAL0.22J1W
R220FR£ C060R22065050 R,METAL0.22J1W
R220SB£ C060R22065050 R,METAL0.22J1W
R220SL£ C060R22065050 R,METAL0.22J1W
R220SR£ C060R22065050 R,METAL0.22J1W
R221C£ C060R22065050 R,METAL0.22J1W
R221FL£ C060R22065050 R,METAL0.22J1W
R221FR£ C060R22065050 R,METAL0.22J1W
R221SB£ C060R22065050 R,METAL0.22J1W
R221SL£ C060R22065050 R,METAL0.22J1W
R221SR£ C060R22065050 R,METAL0.22J1W
R222C£ C060R22065050 R,METAL0.22J1W
R222FL£ C060R22065050 R,METAL0.22J1W
R222FR£ C060R22065050 R,METAL0.22J1W
R222SB£ C060R22065050 R,METAL0.22J1W
R222SL£ C060R22065050 R,METAL0.22J1W
R222SR£ C060R22065050 R,METAL0.22J1W
R223C£ C060R22065050 R,METAL0.22J1W
R223FL£ C060R22065050 R,METAL0.22J1W
R223FR£ C060R22065050 R,METAL0.22J1W
R223SB£ C060R22065050 R,METAL0.22J1W
R223SL£ C060R22065050 R,METAL0.22J1W
R223SR£ C060R22065050 R,METAL0.22J1W
R228C£ C060010065520 R,METAL101W
R228FL£ C060010065520 R,METAL101W
R228FR£ C060010065520 R,METAL101W
R228SB£ C060010065520 R,METAL101W
R228SL£ C060010065520 R,METAL101W
R228SR£ C060010065520 R,METAL101W
R229£ C060010065050 R,METAL10J1W
R230£ C060047166060 R,METAL470J2W
R231£ C060047166060 R,METAL470J2W
RLY201 G680120202020 RELAY,RSB12DC12V
FRONT PCB ASSY [E]
REF.NO. PARTSNO. DESCRIPTION
7028063211040 FRONTPCBASSY[E]
7020063210000 FRONTPCB
CP704 L102526803010 CNWAFER,5268‑03A
CP705 L131524921720 CNFPC,52492‑172017P
