−18−
FRONT PCB ASSY [E]
REF.NO. PARTSNO. DESCRIPTION
D702 K000013300520 D,1SS133T‑72
D703 K000013300520 D,1SS133T‑72
D704 K000013300520 D,1SS133T‑72
DZ707 K06012R044520 D,ZENERMTZJ12B
FLT701 K530125000010 DISPLAY,FLTHNA‑12MM50
HOLDER 4320210091010 HOLDER,FLT
IC700 J127631500010 IC,PT6315
JK700 G402041810090 JACK,S‑VIDEO
JK701 G606040320020 TERMINAL,RCA3PIN
L700 D330101001020 COIL,FILTER‑INDUCTOR100UH
L701 D330100700520 COIL,FILTER‑INDUCTOR10UH
LED700 K500056000050 LED,ML50B13H‑BEC‑T/P(BLUE)
LED701 K500033000020 LED,HL‑30CNYUF2T(YELLOW)
LED702 K500056000050 LED,ML50B13H‑BEC‑T/P(BLUE)
LED703 K500033000020 LED,HL‑30CNYUF2T(YELLOW)
Q700 J6020107M0010 TR,KRC107M
Q701 J601107M00050 TR,KRA107M
Q702 J6020107M0010 TR,KRC107M
Q703 J6020107M0010 TR,KRC107M
Q705 J6020107M0010 TR,KRC107M
Q706 J601107M00050 TR,KRA107M
Q707 J6020107M0010 TR,KRC107M
RMC700 E940643800000 MODULE,REMOCONNJL64H380A
SW700 G180000270010 SW,TACTSKHV10920A
SW701 G180000270010 SW,TACTSKHV10920A
SW702 G180000270010 SW,TACTSKHV10920A
SW704 G180000270010 SW,TACTSKHV10920A
SW706 G180000270010 SW,TACTSKHV10920A
SW708 G180000270010 SW,TACTSKHV10920A
SW710‑SW729 G180000270010 SW,TACTSKHV10920A
VR700 G121162430400 SW,ENCODEREC16B24304
FRONT PCB ASSY [A,K]
REF.NO. PARTSNO. DESCRIPTION
7028063211020 FRONTPCBASSY[A,K]
7020063210000 FRONTPCB
CP704 L102526803010 CNWAFER,5268‑03A
CP705 L131524921720 CNFPC,52492‑172017P
D702 K000013300520 D,1SS133T‑72
D703 K000013300520 D,1SS133T‑72
D704 K000013300520 D,1SS133T‑72
DZ707 K06012R044520 D,ZENERMTZJ12B
FLT701 K530125000010 DISPLAY,FLTHNA‑12MM50
HOLDER 4320210091010 HOLDER,FLT
IC700 J127631500010 IC,PT6315
JK700 G402041810090 JACK,S‑VIDEO
JK701 G606040320020 TERMINAL,RCA3PIN
L700 D330101001020 COIL,FILTER‑INDUCTOR100UH
L701 D330100700520 COIL,FILTER‑INDUCTOR10UH
LED700 K500056000050 LED,ML50B13H‑BEC‑T/P(BLUE)
LED701 K500033000020 LED,HL‑30CNYUF2T(YELLOW)
LED702 K500056000050 LED,ML50B13H‑BEC‑T/P(BLUE)
FRONT PCB ASSY [A,K]
REF.NO. PARTSNO. DESCRIPTION
LED703 K500033000020 LED,HL‑30CNYUF2T(YELLOW)
Q700 J6020107M0010 TR,KRC107M
Q701 J601107M00050 TR,KRA107M
Q702 J6020107M0010 TR,KRC107M
Q703 J6020107M0010 TR,KRC107M
Q705 J6020107M0010 TR,KRC107M
Q706 J601107M00050 TR,KRA107M
Q707 J6020107M0010 TR,KRC107M
RMC700 E940643800000 MODULE,REMOCONNJL64H380A
SW703 G180000270010 SW,TACTSKHV10920A
SW705 G180000270010 SW,TACTSKHV10920A
SW707 G180000270010 SW,TACTSKHV10920A
SW709 G180000270010 SW,TACTSKHV10920A
SW713‑SW729 G180000270010 SW,TACTSKHV10920A
VR700 G121162430400 SW,ENCODEREC16B24304
FRONT PCB ASSY [CN]
REF.NO. PARTSNO. DESCRIPTION
7028063211060 FRONTPCBASSY[CN]
7020063210000 FRONTPCB
CP704 L102526803010 CNWAFER,5268‑03A
CP705 L131524921720 CNFPC,52492‑172017P
D702 K000013300520 D,1SS133T‑72
D703 K000013300520 D,1SS133T‑72
D704 K000013300520 D,1SS133T‑72
DZ707 K06012R044520 D,ZENERMTZJ12B
FLT701 K530125000010 DISPLAY,FLTHNA‑12MM50
HOLDER 4320210091010 HOLDER,FLT
IC700 J127631500010 IC,PT6315
JK700 G402041810090 JACK,S‑VIDEO
JK701 G606040320000 TERMINAL,RCA3PIN
L700 D330101001020 COIL,FILTER‑INDUCTOR100UH
L701 D330100700520 COIL,FILTER‑INDUCTOR10UH
LED700 K500056000050 LED,ML50B13H‑BEC‑T/P(BLUE)
LED701 K500033000020 LED,HL‑30CNYUF2T(YELLOW)
LED702 K500056000050 LED,ML50B13H‑BEC‑T/P(BLUE)
LED703 K500033000020 LED,HL‑30CNYUF2T(YELLOW)
Q700 J6020107M0010 TR,KRC107M
Q701 J601107M00050 TR,KRA107M
Q702 J6020107M0010 TR,KRC107M
Q703 J6020107M0010 TR,KRC107M
Q705 J6020107M0010 TR,KRC107M
Q706 J601107M00050 TR,KRA107M
Q707 J6020107M0010 TR,KRC107M
RMC700 E940643800000 MODULE,REMOCONNJL64H380A
SW703 G180000270010 SW,TACTSKHV10920A
SW705 G180000270010 SW,TACTSKHV10920A
SW707 G180000270010 SW,TACTSKHV10920A
SW709 G180000270010 SW,TACTSKHV10920A
SW713‑SW729 G180000270010 SW,TACTSKHV10920A
VR700 G121162430400 SW,ENCODEREC16B24304
