−19−
MULTI PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
7028063212010 MULTIPCBASSY
VR701 G121161220000 SW,ENCODEREC16B12204
DSP PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
7028063241020 DSPPCBASSY
7020063240000 DSPPCB
BD803 7610035500030 COIL,BEADBFS3550R2F
BD804 D340160800060 COIL,BEADMB‑160808‑0120H
BD805 7610035500030 COIL,BEADBFS3550R2F
BD807 D340160800060 COIL,BEADMB‑160808‑0120H
BD808 D340160800060 COIL,BEADMB‑160808‑0120H
BD809 D340160800060 COIL,BEADMB‑160808‑0120H
BD811 D340160800060 COIL,BEADMB‑160808‑0120H
BD812 7610035500030 COIL,BEADBFS3550R2F
CP800 L101100031810 CNWAFER,TUC‑P18X‑B1
CP801 L101100031710 CNWAFER,TUC‑P17X‑B1
D800 K005041480020 D,CHIP1N4148W
D801 K005041480020 D,CHIP1N4148W
D802 K005041480020 D,CHIP1N4148W
D803 K005041480020 D,CHIP1N4148W
D804 K005041480020 D,CHIP1N4148W
D805 K005041480020 D,CHIP1N4148W
D806 K005041480020 D,CHIP1N4148W
D807 K005041480020 D,CHIP1N4148W
D808 K005041480020 D,CHIP1N4148W
D809 K005041480020 D,CHIP1N4148W
D810 K000400700520 D,IN4007
IC800 J080458800010 IC,AK4588
IC801£ J126111725020 IC,RC1117‑2.5
IC802£ J12603R300010 IC,BA033T
IC803 J040742440180 IC,MM74LCX244
IC804 J040742440180 IC,MM74LCX244
IC805 J080494000010 IC,CS49400
IC806 J040742440190 IC,MM74HCT244
IC807 J040742440190 IC,MM74HCT244
IC808 J001421610010 IC,RAMIS42S16100
IC809 J000298070010 IC,EEPROMEN29LV800AT‑70TC
IC811 J040740400260 IC,74VHCU04
IC901 J121455800150 IC,CJ4558CP
IC902 J121455800150 IC,CJ4558CP
IC903 J121455800150 IC,CJ4558CP
IC904 J121455800150 IC,CJ4558CP
JACK804 G601020130100 TERMINAL,RCA2PIN
JK801 E100116500010 MODULE,OPTICALTRANSMITTER
JK803 E100116500020 MODULE,OPTICALRECEIVER
L800 D3302R2000150 COIL,FILTER‑INDUCTOR2.2UH
L801 D3304R7000150 COIL,FILTER‑INDUCTOR4.7UH
L803 D3304R7000150 COIL,FILTER‑INDUCTOR4.7UH
L804 D3302R2000150 COIL,FILTER‑INDUCTOR2.2UH
Q801 J522107S00210 TR,CHIPKRC107S(NH)
Q802 J5200107S0050 TR,CHIPKRA107S(PH)
DSP PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
Q803 J5200107S0050 TR,CHIPKRA107S(PH)
Q901FL J5222875B0010 TR,CHIPKTC2875B(MB)
Q901FR J5222875B0010 TR,CHIPKTC2875B(MB)
Q902SL J5222875B0010 TR,CHIPKTC2875B(MB)
Q902SR J5222875B0010 TR,CHIPKTC2875B(MB)
Q903SBL J5222875B0010 TR,CHIPKTC2875B(MB)
Q903SBR J5222875B0010 TR,CHIPKTC2875B(MB)
Q904C J5222875B0010 TR,CHIPKTC2875B(MB)
Q904SW J5222875B0010 TR,CHIPKTC2875B(MB)
XTAL800 E80012R288080 CRYSTAL,12.288MHZ
VIDEO PCB ASSY [E,A,CN]
REF.NO. PARTSNO. DESCRIPTION
7028063221040 VIDEOPCBASSY[E,A,CN]
7020063220000 VIDEOPCB
CP101 L101220050010 CNWAFER,GIL‑S‑5P‑S2L2‑EF
CP103 L101220040010 CNWAFER,GIL‑S‑04P‑S2L2‑EF
CP105 L101100031110 CNWAFER,TUC‑P11X‑B1
D100 K000013300520 D,1SS133T‑72
D101 K000013300520 D,1SS133T‑72
D102 K000013300520 D,1SS133T‑72
IC102 J171795600010 IC,LA7956
IC103 J171795600010 IC,LA7956
IC104 J171795600010 IC,LA7956
IC601£ J126780500400 IC,CJ7805F
JK101 G601802002010 TERMINAL,RCA2PIN
JK102 G601802002010 TERMINAL,RCA2PIN
L100 D330220001020 COIL,FILTER‑INDUCTOR22UH
L103 7610035500030 COIL,BEADBFS3550R2F
Q101 J5021740S0010 TR,2SC1740SR
Q102 J5021740S0010 TR,2SC1740SR
Q103 J5021740S0010 TR,2SC1740SR
Q104 J5021740S0010 TR,2SC1740SR
Q105 J5021740S0010 TR,2SC1740SR
Q106 J5021740S0010 TR,2SC1740SR
Q107 J6020107M0010 TR,KRC107M
Q108 J6020107M0010 TR,KRC107M
Q109 J6020107M0010 TR,KRC107M
Q110 J6020107M0010 TR,KRC107M
Q111 J6020107M0010 TR,KRC107M
Q112 J6020107M0010 TR,KRC107M
VIDEO PCB ASSY [K]
REF.NO. PARTSNO. DESCRIPTION
7028063221020 VIDEOPCBASSY[K]
7020063220000 VIDEOPCB
CP101 L101220050010 CNWAFER,GIL‑S‑5P‑S2L2‑EF
CP103 L101220040010 CNWAFER,GIL‑S‑04P‑S2L2‑EF
CP105 L101100031110 CNWAFER,TUC‑P11X‑B1
