VIDEO PCB ASSY [K]
REF.NO. PARTSNO. DESCRIPTION
D100 K000013300520 D,1SS133T‑72
D101 K000013300520 D,1SS133T‑72
D102 K000013300520 D,1SS133T‑72
IC102 J171795600010 IC,LA7956
IC103 J171795600010 IC,LA7956
IC104 J171795600010 IC,LA7956
IC601£ J126780500400 IC,CJ7805F
JK101 G601802002010 TERMINAL,RCA2PIN
JK102 G601802002010 TERMINAL,RCA2PIN
L100 D330220001020 COIL,FILTER‑INDUCTOR22UH
L103 7610035500030 COIL,BEADBFS3550R2F
Q101 J5021740S0010 TR,2SC1740SR
Q102 J5021740S0010 TR,2SC1740SR
Q103 J5021740S0010 TR,2SC1740SR
Q104 J5021740S0010 TR,2SC1740SR
Q105 J5021740S0010 TR,2SC1740SR
Q106 J5021740S0010 TR,2SC1740SR
Q107 J6020107M0010 TR,KRC107M
Q108 J6020107M0010 TR,KRC107M
Q109 J6020107M0010 TR,KRC107M
Q110 J6020107M0010 TR,KRC107M
Q111 J6020107M0010 TR,KRC107M
Q112 J6020107M0010 TR,KRC107M
COMPONENT PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
7028063232020 COMPONENTPCBASSY
IC106 J040744053040 IC,MM74HC4053MX
IC107 J170258000010 IC,NJM2580M
JACK103 G606030164010 TERMINAL,RCA3PIN
JACK104 G606030164010 TERMINAL,RCA3PIN
JACK105 G606030164010 TERMINAL,RCA3PIN
Q100 J6020107M0010 TR,KRC107M
ST-BY PCB ASSY [E]
REF.NO. PARTSNO. DESCRIPTION
7028063231050 ST‑BYPCBASSY[E]
7020063230000 ST‑BYPCB
C314£ D040102084060 C,ELECT1000UFM25V
C331£ D00847208K070 C,CERAMICAC13F472MDOA
CP304£ L104353280201 CNWAFER,35328‑0211(BLACK)
CP305£ L104353280200 CNWAFER,35328‑0210
CP306£ L104353280203 CNWAFER,35328‑0213(BLUE)
D302 K000013300520 D,1SS133T‑72
D313 K000013300520 D,1SS133T‑72
D314 K000013300520 D,1SS133T‑72
D315£ K000400700520 D,IN4007
D316£ K000400700520 D,IN4007
D317£ K000400700520 D,IN4007
D318£ K000400700520 D,IN4007
ST-BY PCB ASSY [E]
REF.NO. PARTSNO. DESCRIPTION
D323 K000013300520 D,1SS133T‑72
DZ304 K06020R044520 D,ZENERMTZJ20B
DZ308 K06005R644520 D,ZENERMTZJ5.6B
F300£ N751224001110 FUSE,T4A250V
F301£ N751222501110 FUSE,T2.5A250V
GT304 3790040876010 TERMINAL,GNDPLATE
GT305 3790040876010 TERMINAL,GNDPLATE
IC300£ J126780500400 IC,CJ7805F
IC302£ J120001500030 IC,ICP‑N15
JACK106£ G435040110000 SOCKET,POWERRECEPTACLE
P300A G645000050010 HOLDER,FUSECLIP
P300B G645000050010 HOLDER,FUSECLIP
P301A G645000050010 HOLDER,FUSECLIP
P301B G645000050010 HOLDER,FUSECLIP
PT302£ 8200280150130 POWERTRANS,STAND‑BY230V
Q300 J5021740S0010 TR,2SC1740SR
Q302 J6020107M0010 TR,KRC107M
Q313 J5021740S0010 TR,2SC1740SR
RLY304£ G680090102010 RELAY,G5PA‑1DC9V
ST-BY PCB ASSY [A]
REF.NO. PARTSNO. DESCRIPTION
7028063231080 ST‑BYPCBASSY[A]
7020063230000 ST‑BYPCB
C314£ D040102084060 C,ELECT1000UFM25V
C331£ D00847208K070 C,CERAMICAC13F472MDOA
CP304£ L104353280201 CNWAFER,35328‑0211(BLACK)
CP305£ L104353280200 CNWAFER,35328‑0210
CP306£ L104353280203 CNWAFER,35328‑0213(BLUE)
D302 K000013300520 D,1SS133T‑72
D313 K000013300520 D,1SS133T‑72
D314 K000013300520 D,1SS133T‑72
D315£ K000400700520 D,IN4007
D316£ K000400700520 D,IN4007
D317£ K000400700520 D,IN4007
D318£ K000400700520 D,IN4007
D323 K000013300520 D,1SS133T‑72
DZ304 K06020R044520 D,ZENERMTZJ20B
DZ308 K06005R644520 D,ZENERMTZJ5.6B
F300£ N751224001110 FUSE,T4A250V
GT304 3790040876010 TERMINAL,GNDPLATE
GT305 3790040876010 TERMINAL,GNDPLATE
IC300£ J126780500400 IC,CJ7805F
IC302£ J120001500030 IC,ICP‑N15
P300A G645000050010 HOLDER,FUSECLIP
P300B G645000050010 HOLDER,FUSECLIP
PT302£ 8200280150130 POWERTRANS,STAND‑BY230V
Q300 J5021740S0010 TR,2SC1740SR
Q302 J6020107M0010 TR,KRC107M
Q313 J5021740S0010 TR,2SC1740SR
RLY304£ G680090102010 RELAY,G5PA‑1DC9V
