−5−
EXPLODED VIEW LIST
REF.NO. PARTSNO. DESCRIPTION REMARKS
1 5088210788000Z KNOBASSY[E,A,K]
5088210788010Z KNOBASSY[CN]
2 5077210973020 WINDOW,DISPLAY
3 4317211141000 COVER,RCA[E,A,K]
4317211141010 COVER,RCA[CN]
4 3067211198050 PANEL,FRONT[E]
3067211198040 PANEL,FRONT[A,K]
3067211198080 PANEL,FRONT[CN]
5 5630210328000 BADGE[E,A,K]
5630210328010 BADGE[CN]
6 5160210093000 INDICATOR,LED
7 3417210091000 BODY[E,A,K]
3417210091010 BODY[CN]
8 5097211981020 BUTTON,9KEY‑RDS[E]
5097211991020 BUTTON,4KEY[A,K]
5097211991040 BUTTON,4KEY[CN]
9 7028063233010 ST‑BYSWPCBASSY
10 5097211971000 BUTTON,POWER[E,A,K]
5097211971010 BUTTON,POWER[CN]
11 4010210876000 BRACKET,POWER
12 7028063234010 POWERSWPCBASSY
13 7028063236010 HPPCBASSY[E,A,K]
7028063236020 HPPCBASSY[CN]
14 5160040643010 INDICATOR,STAND‑BY
15 7028063212010 MULTIPCBASSY
16 7028063211040 FRONTPCBASSY[E]
7028063211020 FRONTPCBASSY[A,K]
7028063211060 FRONTPCBASSY[CN]
17 K530125000010 DISPLAY,FLTHNA‑12MM50
18 4320210091010 HOLDER,FLT
19 2120210678000 HEATSINK
22 4010056906010 BRACKET,HEATSINK
23 7028063261010 AMPPCBASSY
24 3200211166000 CHASSIS,MAIN
25 4300040561010 SPACER,KNOB
26 4007040241040 FOOT[E,A,K]
4007040241050 FOOT[CN]
27 7028063251070 MAINPCBASSY[E]
70280632510D0 MAINPCBASSY[A,CN]
7028063251080 MAINPCBASSY[K]
28 2120210748020 HEATSINK
29 G602405B0400Y TERMINAL,RCA4PIN
30 G607902AA101Y TERMINAL,RCA9PIN
31 G601207E0200Y TERMINAL,RCA2PIN
32 G614801A1400Y TERMINAL,BOARDSCREW8P
33 G612405E1200Y TERMINAL,BOARDSCREW4P
34 7028063241020 DSPPCBASSY
35 G601020130100 TERMINAL,RCA2PIN
36 E100116500010 MODULE,OPTICALTRANSMITTER
37 E100116500020 MODULE,OPTICALRECEIVER
38 7028063221040 VIDEOPCBASSY[E,A,CN]
7028063221020 VIDEOPCBASSY[K]
39 G601802002010 TERMINAL,RCA2PIN
