−16−
MAIN PCB ASSY [K]
REF.NO. PARTSNO. DESCRIPTION
D306 K000013300520 D,1SS133T‑72
D307 K000013300520 D,1SS133T‑72
D309 K005041480020 D,CHIP1N4148W
D310 K005041480020 D,CHIP1N4148W
D311 K005041480020 D,CHIP1N4148W
D319 K000013300520 D,1SS133T‑72
D320 K000013300520 D,1SS133T‑72
D321 K000013300520 D,1SS133T‑72
D322 K000013300520 D,1SS133T‑72
D325 K06005R144520 D,ZENERMTZJ5.1B
D327 K000013300520 D,1SS133T‑72
D328£ K000400700520 D,IN4007
D329£ K000400700520 D,IN4007
D330£ K000400700520 D,IN4007
D331£ K000400700520 D,IN4007
D332£ K000400700520 D,IN4007
D333£ K000400700520 D,IN4007
D334£ K047604000020 D,BRIDGEKBPC604
D335£ K047604000020 D,BRIDGEKBPC604
D501 K005041480020 D,CHIP1N4148W
D502 K005041480020 D,CHIP1N4148W
D505 K005041480020 D,CHIP1N4148W
D506 K005041480020 D,CHIP1N4148W
D507 K005041480020 D,CHIP1N4148W
D508 K005041480020 D,CHIP1N4148W
D509 K005041480020 D,CHIP1N4148W
D510 K005041480020 D,CHIP1N4148W
D511 K005041480020 D,CHIP1N4148W
D512 K005041480020 D,CHIP1N4148W
D515 K005041480020 D,CHIP1N4148W
D516 K005041480020 D,CHIP1N4148W
D517 K000013300520 D,1SS133T‑72
D518 K000013300520 D,1SS133T‑72
D520 K000013300520 D,1SS133T‑72
D521 K000400700520 D,IN4007
DZ300 K06016R044520 D,ZENERMTZJ16B
DZ301 K06016R044520 D,ZENERMTZJ16B
DZ510 K06007R544530 D,ZENERMTZJ7.5A
DZ511 K06007R544530 D,ZENERMTZJ7.5A
DZ512 K06003R344520 D,ZENERMTZJ3.3B
GND303 3790040876010 TERMINAL,GNDPLATE
GND304 3790040876010 TERMINAL,GNDPLATE
IC301£ J126781200220 IC,CJ7812F
IC303£ J126780500400 IC,CJ7805F
IC304£ J126781200220 IC,CJ7812F
IC305£ J126791200130 IC,CJ7912F
IC501 J020703210105 IC,CPUUPD703210YGC‑105‑8BT
IC502 J000240860010 IC,EEPROMMC24C08‑WMN6
IC508 J121455800150 IC,CJ4558CP
IC509 J084115700010 IC,NJW1157
JK302 G612405E1200Y TERMINAL,BOARDSCREW4P
JK303 G614801A1400Y TERMINAL,BOARDSCREW8P
JK304 G601207E0200Y TERMINAL,RCA2PIN
JK305 G602405B0400Y TERMINAL,RCA4PIN
JK306 G607902AA101Y TERMINAL,RCA9PIN
MAIN PCB ASSY [K]
REF.NO. PARTSNO. DESCRIPTION
JK307 G602405B0400Y TERMINAL,RCA4PIN
JK308 G602405B0400Y TERMINAL,RCA4PIN
Q301£ J5000916Y0050 TR,KSA916Y
Q303 J5001266Y0050 TR,KTA1266Y
Q304 J5023198Y0000 TR,KTC3198Y
Q307 J5020107S0050 TR,CHIPKRC107S
Q308 J5020107S0050 TR,CHIPKRC107S
Q309 J5020107S0050 TR,CHIPKRC107S
Q311 J5023198Y0000 TR,KTC3198Y
Q312 J5023198Y0000 TR,KTC3198Y
Q314 J5023198Y0000 TR,KTC3198Y
Q315 J5023198Y0000 TR,KTC3198Y
Q316 J5001268B0050 TR,KTA1268BL
Q317 J5023198Y0000 TR,KTC3198Y
Q318 J5001268B0050 TR,KTA1268BL
Q319 J5001268B0050 TR,KTA1268BL
Q320 J5023198Y0000 TR,KTC3198Y
Q321 J5023198Y0000 TR,KTC3198Y
Q322 J5001268B0050 TR,KTA1268BL
Q323 J5001268B0050 TR,KTA1268BL
Q324 J5001268B0050 TR,KTA1268BL
Q507 J5200107S0050 TR,CHIPKRA107S(PH)
Q508 J5200107S0050 TR,CHIPKRA107S(PH)
Q509 J5200107S0050 TR,CHIPKRA107S(PH)
Q510 J5200107S0050 TR,CHIPKRA107S(PH)
Q511 J5200107S0050 TR,CHIPKRA107S(PH)
Q512 J5222875B0010 TR,CHIPKTC2875B(MB)
Q513 J5222875B0010 TR,CHIPKTC2875B(MB)
Q514 J5222875B0010 TR,CHIPKTC2875B(MB)
Q515 J5222875B0010 TR,CHIPKTC2875B(MB)
Q516 J5222875B0010 TR,CHIPKTC2875B(MB)
Q517 J5222875B0010 TR,CHIPKTC2875B(MB)
Q518 J5222875B0010 TR,CHIPKTC2875B(MB)
Q521 J5222875B0010 TR,CHIPKTC2875B(MB)
Q522 J5200107S0050 TR,CHIPKRA107S(PH)
Q525 J5222875B0010 TR,CHIPKTC2875B(MB)
Q543 J5222875B0010 TR,CHIPKTC2875B(MB)
Q544 J522010200210 TR,CHIPKRC102S(NB)
R304£ C0604R7065050 R,METAL4.7J1W
R315£ C060010065050 R,METAL10J1W
R317£ C060010065050 R,METAL10J1W
R318£ C060010065050 R,METAL10J1W
R319£ C060010065050 R,METAL10J1W
R320£ C060010065050 R,METAL10J1W
R321£ C060010065050 R,METAL10J1W
R336£ C060022265050 R,METAL2.2KJ1W
R338£ C060022265050 R,METAL2.2KJ1W
R342£ C060022265050 R,METAL2.2KJ1W
R351£ C141R10069000 R,CEMENT0.1J5W
R352£ C141R10069000 R,CEMENT0.1J5W
R354£ C060R22065050 R,METAL0.22J1W
R355£ C060R22065050 R,METAL0.22J1W
R356£ C060R22065050 R,METAL0.22J1W
R359£ C060R22065050 R,METAL0.22J1W
R516£ C1012R2064060 R,FUSIBLEMETAL2.2J1/2W
