−15−
MAIN PCB ASSY [A,CN]
REF.NO. PARTSNO. DESCRIPTION
GND303 3790040876010 TERMINAL,GNDPLATE
GND304 3790040876010 TERMINAL,GNDPLATE
IC301£ J126781200220 IC,CJ7812F
IC303£ J126780500400 IC,CJ7805F
IC304£ J126781200220 IC,CJ7812F
IC305£ J126791200130 IC,CJ7912F
IC501 J020703210105 IC,CPUUPD703210YGC‑105‑8BT
IC502 J000240860010 IC,EEPROMMC24C08‑WMN6
IC508 J121455800150 IC,CJ4558CP
IC509 J084115700010 IC,NJW1157
JK302 G612405E1200Y TERMINAL,BOARDSCREW4P
JK303 G614801A1400Y TERMINAL,BOARDSCREW8P
JK304 G601207E0200Y TERMINAL,RCA2PIN
JK305 G602405B0400Y TERMINAL,RCA4PIN
JK306 G607902AA101Y TERMINAL,RCA9PIN
JK307 G602405B0400Y TERMINAL,RCA4PIN
JK308 G602405B0400Y TERMINAL,RCA4PIN
Q301£ J5000916Y0050 TR,KSA916Y
Q303 J5001266Y0050 TR,KTA1266Y
Q304 J5023198Y0000 TR,KTC3198Y
Q307 J5020107S0050 TR,CHIPKRC107S
Q308 J5020107S0050 TR,CHIPKRC107S
Q309 J5020107S0050 TR,CHIPKRC107S
Q311 J5023198Y0000 TR,KTC3198Y
Q312 J5023198Y0000 TR,KTC3198Y
Q314 J5023198Y0000 TR,KTC3198Y
Q315 J5023198Y0000 TR,KTC3198Y
Q316 J5001268B0050 TR,KTA1268BL
Q317 J5023198Y0000 TR,KTC3198Y
Q318 J5001268B0050 TR,KTA1268BL
Q319 J5001268B0050 TR,KTA1268BL
Q320 J5023198Y0000 TR,KTC3198Y
Q321 J5023198Y0000 TR,KTC3198Y
Q322 J5001268B0050 TR,KTA1268BL
Q323 J5001268B0050 TR,KTA1268BL
Q324 J5001268B0050 TR,KTA1268BL
Q507 J5200107S0050 TR,CHIPKRA107S(PH)
Q508 J5200107S0050 TR,CHIPKRA107S(PH)
Q509 J5200107S0050 TR,CHIPKRA107S(PH)
Q510 J5200107S0050 TR,CHIPKRA107S(PH)
Q511 J5200107S0050 TR,CHIPKRA107S(PH)
Q512 J5222875B0010 TR,CHIPKTC2875B(MB)
Q513 J5222875B0010 TR,CHIPKTC2875B(MB)
Q514 J5222875B0010 TR,CHIPKTC2875B(MB)
Q515 J5222875B0010 TR,CHIPKTC2875B(MB)
Q516 J5222875B0010 TR,CHIPKTC2875B(MB)
Q517 J5222875B0010 TR,CHIPKTC2875B(MB)
Q518 J5222875B0010 TR,CHIPKTC2875B(MB)
Q521 J5222875B0010 TR,CHIPKTC2875B(MB)
Q522 J5200107S0050 TR,CHIPKRA107S(PH)
Q525 J5222875B0010 TR,CHIPKTC2875B(MB)
Q543 J5222875B0010 TR,CHIPKTC2875B(MB)
Q544 J522010200210 TR,CHIPKRC102S(NB)
R304£ C0604R7065050 R,METAL4.7J1W
R315£ C060010065050 R,METAL10J1W
MAIN PCB ASSY [A,CN]
REF.NO. PARTSNO. DESCRIPTION
R317£ C060010065050 R,METAL10J1W
R318£ C060010065050 R,METAL10J1W
R319£ C060010065050 R,METAL10J1W
R320£ C060010065050 R,METAL10J1W
R321£ C060010065050 R,METAL10J1W
R336£ C060022265050 R,METAL2.2KJ1W
R338£ C060022265050 R,METAL2.2KJ1W
R342£ C060022265050 R,METAL2.2KJ1W
R351£ C141R10069000 R,CEMENT0.1J5W
R352£ C141R10069000 R,CEMENT0.1J5W
R354£ C060R22065050 R,METAL0.22J1W
R355£ C060R22065050 R,METAL0.22J1W
R356£ C060R22065050 R,METAL0.22J1W
R359£ C060R22065050 R,METAL0.22J1W
R516£ C1012R2064060 R,FUSIBLEMETAL2.2J1/2W
R517£ C1012R2064060 R,FUSIBLEMETAL2.2J1/2W
R518£ C060010165060 R,METAL100J1W
R519£ C060010165060 R,METAL100J1W
RLY300 G680120502040 RELAY,G5PA‑28‑NWDC12V
RLY301 G680120502040 RELAY,G5PA‑28‑NWDC12V
RLY302 G680120502040 RELAY,G5PA‑28‑NWDC12V
XTAL501 E830100000060 RESONATOR,CERAMIC
MAIN PCB ASSY [K]
REF.NO. PARTSNO. DESCRIPTION
7028063251080 MAINPCBASSY[K]
7020063250001 MAINPCB
2120210748020 HEATSINK
C326£ D040682083000 C,ELECT6800UFM16V
C329£ D040472084210 C,ELECT4700UFM25V
C330£ D040102084060 C,ELECT1000UFM25V
C340£ D040682088010 C,ELECT6800UFM63V
C341£ D040682088010 C,ELECT6800UFM63V
C348£ D02010406C060 C,POLY0.1UFJ100V
C350£ D02010406C060 C,POLY0.1UFJ100V
C351£ D02010406C060 C,POLY0.1UFJ100V
C352£ D02010406C060 C,POLY0.1UFJ100V
C353£ D02010406C060 C,POLY0.1UFJ100V
CN501 L101100041710 CNWAFER,TUC‑P17P‑B1
CN506 L101100041810 CNWAFER,TUC‑P18P‑B1
CN512 L101100041110 CNWAFER,TUC‑P11P‑B1
CP300 L104353280300 CNWAFER,35328‑0310
CP301 L102526700800 CNWAFER,5267‑08A
CP302 L104353130600 CNWAFER,35313‑0610
CP307 L102526700600 CNWAFER,5267‑06A
CP507 L131111700010 CNFPC,SCB1117‑0017P
CP509 L131111500010 CNFPC,SCB1115‑0015P
CP513 L102526700400 CNWAFER,5267‑04A
CP514 L101220070000 CNWAFER,G1L‑S‑7P‑S2T2‑EF
CP516 L101220040000 CNWAFER,G1L‑S‑4P‑S2T2‑EF
D303 K000013300520 D,1SS133T‑72
D305 K000400700520 D,IN4007
