−14−
MAIN PCB ASSY [E]
REF.NO. PARTSNO. DESCRIPTION
Q512 J5222875B0010 TR,CHIPKTC2875B(MB)
Q513 J5222875B0010 TR,CHIPKTC2875B(MB)
Q514 J5222875B0010 TR,CHIPKTC2875B(MB)
Q515 J5222875B0010 TR,CHIPKTC2875B(MB)
Q516 J5222875B0010 TR,CHIPKTC2875B(MB)
Q517 J5222875B0010 TR,CHIPKTC2875B(MB)
Q518 J5222875B0010 TR,CHIPKTC2875B(MB)
Q521 J5222875B0010 TR,CHIPKTC2875B(MB)
Q522 J5200107S0050 TR,CHIPKRA107S(PH)
Q525 J5222875B0010 TR,CHIPKTC2875B(MB)
Q543 J5222875B0010 TR,CHIPKTC2875B(MB)
Q544 J522010200210 TR,CHIPKRC102S(NB)
R304£ C0604R7065050 R,METAL4.7J1W
R315£ C060010065050 R,METAL10J1W
R317£ C060010065050 R,METAL10J1W
R318£ C060010065050 R,METAL10J1W
R319£ C060010065050 R,METAL10J1W
R320£ C060010065050 R,METAL10J1W
R321£ C060010065050 R,METAL10J1W
R336£ C060022265050 R,METAL2.2KJ1W
R338£ C060022265050 R,METAL2.2KJ1W
R342£ C060022265050 R,METAL2.2KJ1W
R351£ C141R10069000 R,CEMENT0.1J5W
R352£ C141R10069000 R,CEMENT0.1J5W
R354£ C060R22065050 R,METAL0.22J1W
R355£ C060R22065050 R,METAL0.22J1W
R356£ C060R22065050 R,METAL0.22J1W
R359£ C060R22065050 R,METAL0.22J1W
R516£ C1012R2064060 R,FUSIBLEMETAL2.2J1/2W
R517£ C1012R2064060 R,FUSIBLEMETAL2.2J1/2W
R518£ C060010165060 R,METAL100J1W
R519£ C060010165060 R,METAL100J1W
RLY300 G680120502040 RELAY,G5PA‑28‑NWDC12V
RLY301 G680120502040 RELAY,G5PA‑28‑NWDC12V
RLY302 G680120502040 RELAY,G5PA‑28‑NWDC12V
XTAL501 E830100000060 RESONATOR,CERAMIC
XTAL502 E800433200090 CRYSTAL,4.332MHZ
MAIN PCB ASSY [A,CN]
REF.NO. PARTSNO. DESCRIPTION
70280632510D0 MAINPCBASSY[A,CN]
7020063250001 MAINPCB
2120210748020 HEATSINK
C326£ D040682083000 C,ELECT6800UFM16V
C329£ D040472084210 C,ELECT4700UFM25V
C330£ D040102084060 C,ELECT1000UFM25V
C340£ D040682088010 C,ELECT6800UFM63V
C341£ D040682088010 C,ELECT6800UFM63V
C348£ D02010406C060 C,POLY0.1UFJ100V
C350£ D02010406C060 C,POLY0.1UFJ100V
C351£ D02010406C060 C,POLY0.1UFJ100V
C352£ D02010406C060 C,POLY0.1UFJ100V
MAIN PCB ASSY [A,CN]
REF.NO. PARTSNO. DESCRIPTION
C353£ D02010406C060 C,POLY0.1UFJ100V
CN501 L101100041710 CNWAFER,TUC‑P17P‑B1
CN506 L101100041810 CNWAFER,TUC‑P18P‑B1
CN512 L101100041110 CNWAFER,TUC‑P11P‑B1
CP300 L104353280300 CNWAFER,35328‑0310
CP301 L102526700800 CNWAFER,5267‑08A
CP302 L104353130600 CNWAFER,35313‑0610
CP307 L102526700600 CNWAFER,5267‑06A
CP507 L131111700010 CNFPC,SCB1117‑0017P
CP509 L131111500010 CNFPC,SCB1115‑0015P
CP513 L102526700400 CNWAFER,5267‑04A
CP514 L101220070000 CNWAFER,G1L‑S‑7P‑S2T2‑EF
CP516 L101220040000 CNWAFER,G1L‑S‑4P‑S2T2‑EF
D303 K000013300520 D,1SS133T‑72
D305 K000400700520 D,IN4007
D306 K000013300520 D,1SS133T‑72
D307 K000013300520 D,1SS133T‑72
D309 K005041480020 D,CHIP1N4148W
D310 K005041480020 D,CHIP1N4148W
D311 K005041480020 D,CHIP1N4148W
D319 K000013300520 D,1SS133T‑72
D320 K000013300520 D,1SS133T‑72
D321 K000013300520 D,1SS133T‑72
D322 K000013300520 D,1SS133T‑72
D325 K06005R144520 D,ZENERMTZJ5.1B
D327 K000013300520 D,1SS133T‑72
D328£ K000400700520 D,IN4007
D329£ K000400700520 D,IN4007
D330£ K000400700520 D,IN4007
D331£ K000400700520 D,IN4007
D332£ K000400700520 D,IN4007
D333£ K000400700520 D,IN4007
D334£ K047604000020 D,BRIDGEKBPC604
D335£ K047604000020 D,BRIDGEKBPC604
D501 K005041480020 D,CHIP1N4148W
D502 K005041480020 D,CHIP1N4148W
D505 K005041480020 D,CHIP1N4148W
D506 K005041480020 D,CHIP1N4148W
D507 K005041480020 D,CHIP1N4148W
D508 K005041480020 D,CHIP1N4148W
D509 K005041480020 D,CHIP1N4148W
D510 K005041480020 D,CHIP1N4148W
D511 K005041480020 D,CHIP1N4148W
D512 K005041480020 D,CHIP1N4148W
D515 K005041480020 D,CHIP1N4148W
D516 K005041480020 D,CHIP1N4148W
D517 K000013300520 D,1SS133T‑72
D518 K000013300520 D,1SS133T‑72
D520 K000013300520 D,1SS133T‑72
D521 K000400700520 D,IN4007
DZ300 K06016R044520 D,ZENERMTZJ16B
DZ301 K06016R044520 D,ZENERMTZJ16B
DZ510 K06007R544530 D,ZENERMTZJ7.5A
DZ511 K06007R544530 D,ZENERMTZJ7.5A
DZ512 K06003R344520 D,ZENERMTZJ3.3B
