Teac AG-980 - Page 12

12
• Each time this button is pressed, the corresponding tone
mode is selected and shown for 5 seconds as follows:
∑Note:
• When the tone direct function is activated, the tone mode
cannot be entered and “TON DIR” flickers for 3 seconds.
BASS TRBL
Adjusting the tone (bass and treble)
8. Enter the tone mode.
• "TON DIR" is displayed, "DIRECT" lights up and the sound
that bypasses the tone circuitry will be heard.
• To cancel the tone direct function, press this button again to
display "TON CTRL", and then "DIRECT" turns off.
10
. To listen to a program source without the tone effect.
• If the tone display disappears, start from the step 8 again.
• The tone (BASS and TRBL) can be adjusted within the range
of -10 ~ +10 dB.
∑Note:
• Extreme settings at high volume may damage your speak-
ers.
• In general, the bass and treble levels are adjusted to 0.
9. At the desired tone mode, adjust the tone as desired.
